Energy Saving Analysis of TSC&APF Integrated Device

Abstract:

This paper analyzes the construction and control principle of Thyristor Switched Capacitor(TSC) and Active Power Filter(APF) integrated device. An harmonics detection method based on the instantaneous reactive power theory is also discussed. This method is effective to apply to TSC&APF integrated device and can get better result to eliminate the harmonics and compensate reactive power. A new integrated device which consists of TSC and APF is developed with this method. The application in the automobile industry shows that this device is correct and effective. It is a favorable model of improving the power quality and save the energy.

• Periodical: Advanced Materials Research (Volumes 347-353)
• Pages: 2559-2563
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.347-353.2559
• Online since: October 2011
• Authors: Jing Shuang Shen, Chuan Wen Jiang, Yu Jiao Liu, Wei Jun Yun
• Keywords: Active Power Filter (APF), Integrated Device, Power Quality (PQ), Saving Energy, Thyristor Switched Capacitor (TSC)

References

[1] R Gary W. Chang, " A New Approach for Optimal Shunt Active Power Filter Control Considering Alternative Performance Indices", IEEE Transactions on Power Delivery, vol.21, no.1, 2006, pp.406-413. references.

DOI: 10.1109/tpwrd.2005.852347

[2] FUKUDAS,ENDOHT. Control method for a combined active filter system employing a current converter and high pass filter [J]. IEEE Trans on Industry Application. 1995,31(3):590-597.

DOI: 10.1109/28.382120

[3] Sasaki H, Machida T. A new method to eliminate ac harmonic currents by magnetic compensation consideration on basic design. IEEE Transactions on app. And syst., 1971,90(5):2009-2019.

DOI: 10.1109/tpas.1971.292996

[4] M.D. Manjrekar P.K. Steimer,and T.A. Lipo,"Hybrid multilevel power conversion system: A competitive solution for high-power application," IEEE Trans. Ind. Applicat., vol.36, pp.1565-1572, May/June 2000.

DOI: 10.1109/28.845059

[5] G.R. Kamath and N. Mohan,"Series-connected, all-hybrid converters for utility interactive applications." In Proc. IECON'97,1997,pp.726-731.

DOI: 10.1109/iecon.1997.671824

[6] Sangsun Kim, Prasad N Enjeti,"A New Hybrid Active Power Filter(APF)Topology", IEEE Transactions on Power Electronics, vol.17, no.1, 2002,pp.48-54.

DOI: 10.1109/63.988669

[7] LIU Hong-liang    TANG Yu-peng    YU Jie," Study of Dynamic Reactive Power and Harmonic Compensation System Based on a Combination of APF and TSC" ELECTRIC DRIVE, 2008, 38(10), pp.65-68.

[8] Juan Dixon, et al, " A Full Compensating System for General Loads, Based on a Combination of Thyristor Binary Compensator, and a PWM-IGBT Active Power Filter", IEEE Transactions on IndustrialElectronics, vol.50,no.5, 2003, pp.982-989.

DOI: 10.1109/tie.2003.817604

[9] Hongliang Liu,Yepeng Tang. Research on a Hybrid System for Dynamic Reactive Power and Harmonic Compensation. IEEE Proceedings of the 7th World Congress on Intelligent Control and Automation. 2008. pp.6521-6526.

DOI: 10.1109/wcica.2008.4592887
