A New Three Medium Composite Heat Exchanger

Abstract:

The solar-air compound heat pump system which core component is a three medium composite heat exchanger is a new heat pump system. Compared with the conventional air source heat pump system, the COP of the new dual heat source heat pump system is at least increased by 40%, and the energy-saving effect is obvious. At present, the only dual heat source composite heat exchanger used in heat system is a finned-tube three medium composite heat exchanger. With the heat exchanger, the synchronous heat exchange between a liquid heat source, a gaseous heat source and a refrigerant could be realized, and the performance of the heat pump system could be effectively improved. But the structural defects of the finned-tube three medium composite heat exchanger result in processing difficulty, and it is difficult to form a batch production with the present processing technology. The hidden sealing danger of the heat exchanger also exists. In the paper, a new three medium composite heat exchanger has been designed. The structural flaw of the finned-tube three medium composite heat exchanger has been better avoided. And it makes the process easier and the batch production more convenient.

• Periodical: Advanced Materials Research (Volumes 347-353)
• Pages: 3143-3146
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.347-353.3143
• Online since: October 2011
• Authors: Chao Zhang, Jia Yun Dong, Guang Hui Zhou
• Keywords: Composite Heat Exchanger, Dual Heat Source Heat Pump System, Three Medium

References

[1] Na Yu: The heating characteristics of the solar-air compound source heat pump system (Zhongyuan University of Technology, Zhengzhou 2008)

[2] Shengjie Chen: The study of the working mode and characteristics of the air-ground source heat source heat pump (Zhongyuan University of Technology, Zhengzhou 2009)
