Analysis on Performances of Matrix Rectifier under Abnormal Conditions

Abstract:

Matrix rectifier (AC-DC MC) is a four-quadrant AC-DC power converter device with compact topology. This paper concerns the influence of abnormal power supply conditions to the matrix rectifier. The input and output performances of matrix rectifier with pure sinusoidal supply voltages are discussed. The input currents are symmetrical sinusoidal without any low-order components. But due to the absence of DC capacitors, the abnormal conditions at input side affect the input and output performances directly, which introduce ripples into the DC output and cause the distortion of input currents. In this paper, the low-order harmonic components in input currents, and ripples at output side are theoretically analyzed under conditions that the input voltages are unbalanced and non-sinusoidal respectively. The simulation research is carried out to verify the theoretical analysis, and the results, which demonstrated the analysis conclusions, are given.

• Periodical: Advanced Materials Research (Volumes 354-355)
• Pages: 1347-1352
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.354-355.1347
• Online since: October 2011
• Authors: Xiao Liu, Qing Fan Zhang, Dian Li Hou
• Keywords: Harmonics, Matrix Converter, Non-Sinusoidal, Unbalance

References

[1] L. Gyugyi and B. R. Pelly: "Static Power Frequency Changers: Theory, Performance and Application", Wiley Press, 1976.

[2] S. Huseinbegovic and O. Tanovic: "Matrix Converter Based AC/DC Rectifier", IEEE International Conference on Computational Technologies in Electrical and Electronics Engineering (SIBIRCON), 11-15 July , 653-658, 2010.

DOI: 10.1109/sibircon.2010.5555146

[3] S. Ishii, H. Hara, T. Higuchi and T. Kawachi: "Bidirectional DC-AC Conversion Topology Using Matrix Converter Technique", The 2010 International Power Electronics Conference, 21-24 June, 2768-2773, 2010.

DOI: 10.1109/ipec.2010.5543828

[4] R. Baharom, R. Hamzah, K. S. Hamzah and M. K. Muhammad: "Boost Rectifier Using Single-phase Matrix Converter", 3rd IEEE Conference on Industrial Electronics and Applications, 3-5 June, 2205-2210, 2008.

DOI: 10.1109/iciea.2008.4582909

[5] J. Monteiro, J. Fernando Silva, S. F. Pinto and J. Palma: "Matrix Converter-Based Unified Power-Flow Controllers: Advanced Direct Power Control Method", IEEE Trans. On Industrial Electronics, ,Vol. 26, issue1, 420-430, 2011.

DOI: 10.1109/tpwrd.2010.2055897

[6] D. G. Holmes and T. A. Lipo: "Implementation of a Controlled Rectifier Using AC-AC Matrix Converter Theory", IEEE Trans. On Power Electronics, Vol. 7, issue 1, 240-250, 1992.

DOI: 10.1109/63.124596

[7] B. Singh, B. N. Singh, A. Chandra, K. Al-Haddad, A. Pandey and D. P. Kothari: "A Review of Single-Phase Improved Power Quality AC-DC Converters", IEEE Trans. On Industrial Electronics, Vol. 50, issue5, 962-981, 2003.

DOI: 10.1109/tie.2003.817609

[8] A. L. Julian and G. Oriti: "AC-DC Traction Drive Application of a Regenerative Rectifier Using AC/AC Matrix Converter Theory", Conference record of the 2003 IEEE Industry Applications Conference 38th IAS Annual meeting, 12-16 October, 198-204, 2003.

DOI: 10.1109/ias.2003.1257503
