Analysis of Collision Parameter about Collision-Prevention Device of Bridge Pier and Optimum Structural Design

Abstract:

For the purpose of providing useful reference for optimizing the design of Collision-Prevention Device of Bridge Pier, analyzing the collision parameters and putting forward the ideal size of the circular steel tube and angle steel in absorbing energy,the ship impacting the steel tubular truss,which belongs to the Collision-Prevention Device of Bridge Pier, is simulated.The water level of ship and the size of circular steel tube and angle steel are discussed respectively with the ANSYS/LS-DYNA program，which is the nonlinear dynamic analysis software,to study the impact of change of the single collision parameter to the equipment for anti-collision which is the steel tubular truss.when the ship impacts the steel tubular truss under the ideal level,the circular steel tube and the angle steel could play fully in resisting the collision of ship, achieved a better absorbing effect.The circular steel tube can play a chief absorption effect through the bending deformation, while the relatively small energy is absorbed by the angle steel through the buckling deformation. The best sizes selected through the optimum structural design are shown as follows: the diameter of circular steel tube is 800mm; the thickness of tubular wall is 12mm; the size of angle steel is 100mm×100mm×12mm.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 1235-1240
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.1235
• Online since: October 2011
• Authors: Hai Zhang, Shuai Fang, Hua Tao Yin
• Keywords: Collision Parameter, Nonlinear Finite Element, Optimum Structural Design, Ship-Bridge Collision, Steel Tubular Truss

References

[1] Minorsky V.U. An Analysis of Ship Collision to Protection of Nuclear Powered Plant. Journal of Ship Reaearch[J],1959,3(2):1-4

[2] Paik J.K,Petersen P.T. Modelling of the Internal Mechanics in Ship Collisions, Ocean Engineering,1996,23(2):107-142.

DOI: 10.1016/0029-8018(95)00021-6

[3] X.J. Shang, J.N. Shu. Water-Power Press,2006.(In Chinese)

[4] LS-DYNA.Keyword User's Manual.Livermore,California:Livermore Software Technology Coporation,2006.

[5] J.Z. Bai. LS-DYNA3D Theory Foundation and Examples[M].Beijing:Science Press.2005.5

[6] L.Luo.Ship-bridge Collision Theories and Analysis on Anti-collision Equipment of Lie-de Bridge[D].Changsha: Changsha University of Technology,2008.(In Chinese)

[7] B.Xiao, J.Li.Port & Waterway Engineering, 1002-4972（2010）03-0017-04. (In Chinese)

[8] H.R. Jiang.The Numerical Simulation for the Collision between Ship and Bridge Pier Anti-collision Equipment[D],Wuhan: Wuhan University of Technology,2004.(In Chinese)

[9] C.J. Wang C.R. Chen and J.J. Zhang.Foreign Birdges, 2001(4):72-75.(In Chinese)

[10] J.Pan.Study on Mechanism in Ship-bridge Collision and Equipment for Anti-collision[D]. Wuhan: Wuhan University of Technology,2003.(In Chinese)

[11] J.C. Liu, Y.N.Gu and Z.Q.Hu. Highway, 2002,(10): 33-41.(In Chinese)
