Application of Equal Strength Substitution Method on Concrete Beams Strengthened with Steel Plates

Abstract:

To research the applicability of equal strength substitution method applied to concrete beams with steel plates, the effects on application range of equal strength substitution method by the initial reinforcement ratio and the strengthened moment design value are discussed．In this paper, the calculation methods of equivalent substitution and Design Code for Strengthening Concrete Structure are adopted to calculate five kinds of single-reinforced rectangular cross-section concrete beams of typical section size by adjusting the initial reinforcement ratio and the strengthened moment design value．The dosage of steel plates is obtained through the comparison of the equal strength substitution and code calculation methods, which is used to obtain the relationship of initial reinforcement ratio, the area ratio of steel plates calculated by the equal strength substitution and code calculation methods and the moment ratio of strengthened and initial ultimate moment． The result shows that equal strength substitution method is not applicable universally, which is feasible only within the scope of certain．

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 2341-2345
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.2341
• Online since: October 2011
• Authors: Hong Liang Zuo, Chao Zhuang, Lin Lin Zhu
• Keywords: Concrete Beam, Equal Strength Substitution Method, Steel Plate, Strengthen

References

[1] Jiyun Han, in: Transformation technology and engineering examples for the testing of buildings. chapter,4,Chemical Industry Press (2008)．(in Chinese)

[2] Bontea D M, Chung D D , Lee G C．Cement and Concrete Research, Vol.61(2000), p.656．

[3] Chen JF, Teng J G．Journal of Structural Engineering, ASCE, Vol. 127(7) (2001), p.788．

[4] Lam L，Teng J G．Journal of Structural Engineering, ASCE, Vol. 128(5) (2002), p.618．

[5] Yeong Soo, Chadon Lee．ACI structural journal, Vol. 100(2) (2003), p.364．

[6] Sichuan Provincial Academy of Building Research．GB50367-2006 Design code for strengthening concrete structure．Beijing: China Architecture and Building Press,(2006)．(in Chinese)

[7] Ministry of Housing and Urban-Rural Development of the People's Republic of China．GB50010-2002 Code for design of concrete structures．Beijing: China Architecture and Building Press, (2002)．(in Chinese)

[8] Min Yang．Construction Technology, Vol. 23(2) (2009), p.252．(in Chinese)
