Experimental Study on Reasonable Distance of Tunnels with Small Spacing

Abstract:

An experimental methods was used to study the reasonable distance of tunnels with small spacing, four tunnels were located in a model, the distances between them were 0.5D, 1.0D and 1.5D respectively. The results show that the stress is concentrated in the folder of rock due to the superimposed stress fields, intensive vertical cracks emerged in the folder rock, then folder rock buckled, finally, the crown area of the tunnel sank. The thickness of the folder rock is the crucial factor for the stability of the tunnel, when the thickness is less than 0.5D, the folder rock failed first, when the thickness is as much as the span of the tunnel, the individual dilapidated area in the folder rock will not intersected with each other, the middle area of the folder rock is still in a stable state, as a result, the folder rock can maintain in a stable state.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 2621-2624
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.2621
• Online since: October 2011
• Authors: Xian Min Wen, Jian Hui Yang, Han Hua Zhu
• Keywords: Folder of Rock, Reasonable Distance, Tunnel with Small Spacing

References

[1] Liu Yanqing, Zhong Shihang, Lu Rusui, Ma Rongtian. Experimental Study on Mechanical Characteristics of Twin Tunnels with small Spacing: Chinese Journal of Rock Mechanics and Engineering. Vol. 19(2000), p.590

[2] Hu Yuanfang. Stability Analysis of Surrounding Rocks of Double-Hole Urban Tunnel with Small Interval: Chinese Journal of Rock Mechanics and Engineering. Vol. 21(2002), p.1335

[3] Yao Yong, Tian Zhiyu. Study on Mechanical Behavior and Reinforcing Measures of Middle Rock Wall of Parallel Tunnel with Small Interval: Industrial Construction. Vol. 36(2006), p.57

[4] Liu Wei, Jin Xiaoguang, Chen Shaohua. Investigation on Reasonable Clear Interval of Small-interval Tunnel for the Freeway: Underground Space. Vol. 24(2004), p.380

[5] Wang Zhengming, Wang Bo, Huang Qiang. Study on Stress Conditions of Small Interval Tunnel's Surrounding Rock: Engineering and Construction. Vol.20(2006), p.157

[6] Tian Zhiyu. Study on Highway Neighbourhood Tunnel by Similar Model Test: Master Thesis of Southwest Jiaotong University. (2006)

[7] Tian Zhiyu, He Chuan, Rao Yong. Study on reasonable clear distance by model test for twin tunnels with small spacing: National Highway Tunnel Conference Proceedings. (2005), p.37～44

[8] Lu Biao, Xia Yongxu. Research of minimum safe clear distance of highway neigborhood tunnel: National Highway Tunnel Conference Proceedings. (2005), p.44～47

[9] Deng Gang, Li Yuwen. Resolution and application on stress of middle rock pillar to shallow buried neigborhood: National Highway Tunnel Conference Proceedings. (2005), p.47～51
