Numerical Analysis on Vertical Structural Stability of Floating Drilled Shaft during Sinking

Abstract:

The vertical structural stability of floating drilled shaft during sinking is an important practical issue on the safety of boring technique in the deep and thick alluvium. In fact, the vertical structural stability of shaft lining is a matter of overturn buckling. Theoretical analysis shows that the height of balance water (HBW) is the most important factor for the vertical structural stability of shaft lining. If the HBW is controlled in a reasonable range, the shaft lining will not buckle during construction. The shaft lining is regarded as a slender bar with closed bottom and floating in the mud while sinking. According to the mechanical analysis on the shaft lining from floating and sinking to the process of contacting the well bottom, a reasonable range of the HBW is deduced. Finally, with practical instances, the author in this article introduces the calculation principle in vertical structural stability of shaft lining while sinking and floating using finite element method (FEM). The simulation results show that in the reasonable range of HBW, the stability of shaft lining increases as the height of balance water goes up.

• Periodical: Advanced Materials Research (Volumes 368-373)
• Pages: 2625-2629
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.368-373.2625
• Online since: October 2011
• Authors: Ji Min Liu, Chang Bo Wang
• Keywords: Drilled Shaft Lining, Hight of Balance Water (HBW), Overturn Buckling, Vertical Structural Stability

References

[1] Rongli Zhang, Guowei He, Duo Li: Design Manual of Mining Engineering II (China Coal industry of publishing house, Beijing 2004).(In Chinese)

[2] Hua Cheng, Jimin Liu, Chuanxin Rong, Zhishu Yao: Journal of China Coal Society, Vol. 33(12) (2008), p.1351 (In Chinese)

[3] Boqian Hong: Coal Science and Technology, Vol. 34(1) (2006), p.8 (In Chinese)

[4] Boqian Hong: China Coal, Vol. 6(2004), p.9 (In Chinese)

[5] Jimin Liu, Hua Cheng, Chuanxin Rong: Zhongzhou Coal, Vol. 5(2007), p.11 (In Chinese)

[6] Zhuo Zhuang, Fan Zhang, Song Jin et al: ABAQUS Nonlinear finite element analysis and instances , (Science Press, Beijing 2005).(In Chinese)

[7] Xuechao Niu, Boqian Hong, Renshu Yang: Journal of China Coal Society, Vol. 33(11) (2008),p.1235 (In Chinese)
