Research on On-Line High-Voltage Switch Contact Temperature Rise Monitoring System Based on WSN

Abstract:

In order to detect the overheating fault of high-voltage switch contacts in time, and enhance the reliability of power supply system, this paper presents a new method for temperature rise monitoring, it is realized by WSN (wireless sensor network) and electromagnetic coupling which is a power-gaining technology. Based on the above method and technology, the author designs an on-line system to monitor the temperature rise of high-voltage switch contacts and builds a WSN based on ZigBee protocol. The system includes integral temperature collectors and data receiver, and the data between two of them is transmitted wirelessly by using the opening frequency band of 2.4 G provided by wireless module. The integral temperature collector does not need external power for its power is provided directly from high-voltage bus by the principle of electromagnetic coupling. The extensive system tests show the measurement error of temperature is ± 1.5°C, which can meet the temperature measurement requirements of high-voltage switch contacts.

• Periodical: Advanced Materials Research (Volume 382)
• Pages: 210-214
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.382.210
• Online since: November 2011
• Authors: Jin Bo Zhang, Yang Gao, Pei Hao
• Keywords: High-Voltage Switch Contacts, Magnetic Saturation, Small Current Transformer, Temperature Rise, Wireless Sensor Network (WSN)

References

[1] Guangxing Zhao, Fan Zhang. Design on on-line high-voltage switchgear temperature monitoring system based on MSP430[J]. China Instrumentation, 2008, 58: 13-17.

[2] Wu Yang, etc. Research on on-line high-voltage power equipment temperature monitoring sensor based on infrared temperature measurement technology[J]. Proceedings of the CSEE, 2002, 09: 12-15.

[3] Xianwu Cheng. On-line high-voltage switchgear contact temperature monitoring system[J]. Rural network automation, 2009, 8: 34-35.

[4] Meiyu Tao, Haikun Chen. Research on on-line air -insulated high-voltage handcart switchgear circuit breaker contact temperature rise monitoring system[J]. East China Electric Power, 2007, 38 (2): 74-76.

[5] Fengbao Li, Ling Li. Overview of wireless sensor networks[J]. Chinese Journal of Scientific Instrument, 2005, 26: 60-62.

[6] Jin Ji. Application of WSN base on ZigBee in industrial automation monitoring [J]. Industrial Instrumentation & Automation, 2007, 3: 21-23.

[7] Yuzhou Sha etc. Design of self-suppyling power source applied in high voltage electronic system[J]. High Voltage Apparatus, 2007(1): 42-45.

[8] Hang Lv, Li Li. A new method of bus protection and against CT saturation[J]. Automation of Hydropower Plants, 1999, 11: 224-228.

[9] Xuhui Tang. Design on optoelectronic CT high-side power supply[J]. High Voltage Apparatus, 2009, 5: 52-53.
