Navigation System of Mobile Platform Based on Open Architecture for Agricultural Machinery

Abstract:

In order to meet the requirements of agricultural production automation, a PC-based opening navigation system for agricultural machinery is designed, which is composed of PC, data acquisition cards, electromagnetic induction sensors, high-frequency electromagnetic generator, DC servo motor and mechanical part. The track of the mobile platform is led by a wire with high-frequency currents laid under the field. The position can be determined by a pair of electromagnetic induction sensors installed in the machine. The traveling path is planed by computer according to information of electromagnetic induction sensor and automatic walking of agricultural machinery is achieved. Based on Visual C + + 6.0 platform, a system software is developed and human-computer interface with good interaction is designed. The results show that, straight navigation accuracy is ± 1.5cm within 10m; the navigation accuracy is ± 3cm when the turning radius is 0.5m. Experiments explain that the system owns high real-time performance and dependability, and that it has a good application prospect.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 1155-1159
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.1155
• Online since: November 2011
• Authors: Jian Song
• Keywords: DC PWM, Electromagnetic Induction Sensors, Machinery, Navigation System, Open Architecture

References

[1] Song Jian, Zhang Bin, Zhang Tiezhong. Navigation System of Spraying Robot By Electromagnetic guidance. Transactions of the Chinese Society for Agricultural Machinery, vol. 36, pp.151-154, December 2005 (In Chinese).

[2] Yan Shubing, Ji Changying. Present Situation and Development Tendency of Mobile Platform for Agricultural Robots. Tractor and farm Transporter, vol. 34, pp.13-15, October 2007 (In Chinese).

[3] Su Qinghua, Chen Jun. Research onW irelessRemote Control System of Agriculture Mobile Robot. Journal of Agricultural Mechanization Research, vol. 29, pp.115-117, March 2010 (In Chinese).

[4] Shen Mingxia, Ji Changying. Development and Prospect of Vision Guidance of Agricultural Robot. Society for Agricultural Machinery, vol. 32, pp.109-111, January 2001 (In Chinese).

[5] Toru Torii. Research in autonomous agriculture vehicles in Japan. Computers and electronics in agriculture, vol. 25: 133－153, January (2000).

DOI: 10.1016/s0168-1699(99)00060-5

[6] Cong Ming, Jin Ligang, Fang Bo. IntelligentRobotM owers A Review. ROBOT, vol. 29, pp.407-416, July 2007 (In Chinese).

[7] Bjorn Asrand, Albert Jan Baerveldt. An agricultural mobile robot with vision based perception for mechanical weed control. autonomous robots, vol. 13, pp.21-35, April (2002).
