Research on Auto Control System for Ship Loader Based on AC800M

Abstract:

Ship loader is one of the most key equipments for bulk material handing in bulk port. This paper regards the ship loader as the study object, introduces an auto detection technology of cabin position and material distribution, and advances a new control measure for automation loading. The field-bus technology of Profibus, AC800M series PLC, inverter, encoder was adopted to build automatic control system. In the mean time, the control code and the ship loader Management System, which is written in Control Builder for AC800M and Visual Basic independently, are used to actual ship loading process without people.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 1231-1234
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.1231
• Online since: November 2011
• Authors: Wei Liu, Shi Long Xue
• Keywords: AC800M, Automatic Control, Ship Loader

References

[1] Talk on ship loader auto control measure. Yan zhaoji Shanghai Port Machinery Heavy Industry Co., Ltd. 2006. 7.

[2] Basic Control Software Introduction and Configuration. ABB Company, 2005. 5.

[3] AC800M Control Hardware and Operation. ABB Company 2005. 5.

[4] S800 I/O General Information and Instrallation. ABB Company. 2005. 5.

[5] S800 I/O Fieldbus Communication Interface Profibus-DP/DPV1. ABB Company. 2005. 5.

[6] CI858 Drive Bus Communication Interface users' handbook. 2005. 5.

[7] Communication Protocols and Design. ABB Company. 2005. 5.

[8] Compact Control Builder Getting Started Introduction and Insallation. ABB Company. 2005. 5.

[9] Extended Control Software Binary and Analog Handing. ABB Company. 2005. 5.
