Vibration Simulation of Articulated Dump Truck with the Variation of Longitudinal Center of Gravity Position of Rear Sprung Mass and Rear Suspension Stiffness

Abstract:

The paper is concerned with the vibration for the articulated dump truck (ADT) which is multi-axle vehicle and different from rigid dump truck. The balanced suspension was employed as the rear suspension in the 60t ADT which the paper takes as the research object. A vibration model of 6 dof for the truck was proposed. The impact of the variation of longitudinal center of gravity position of rear sprung mass and rear suspension stiffness on vibration was investigated in stochastic excitation of the truck in the frequency domain. It is found that it is beneficial to the comfort of the truck when the center of gravity of the sprung mass moves forward and the impact of rear sprung stiffness on vibration is not too great. The results of the vibration for the truck are provided for the design of the 60t ADT.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 1812-1818
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.1812
• Online since: November 2011
• Authors: Xue Yan Zhang, Wen Ming Zhang
• Keywords: Articulated Dump Truck, Center of Gravity Position, Rear Suspension, Stiffness, Vibration

References

[1] http: /www. volvo. com/constructionequipment/corporate/engb/AboutUs/history/history+track/1966/introduction. htm.

[2] P.J. Liu. (1994). An Analytical Study of Ride and Handling Performance of an Interconnected Vehicle Suspension, M.A. Sc. Thesis, Concordia University.

[3] CHAI Shan, LI Ji-heng, LIU Shu-tian, Lv Feng-jun, WANG Feng-sheng, SUN YiStrength, Analysis for the Vehicle Frame with Series-Arranged Multi-Axes Oil and Air Spring Suspensions, Mechnical Science and Technology, vol. 23, April 2004, pp.408-411.

[4] Chen Ling, The Study of Mining Dump Truck's Ride Quality, Ph.D. thesis, University of Science and Technology Beijing, China.

[5] A.W. Burton, A.J. Truscott, P.E. Wellstead, Analysis, modelling and control of an advanced automotive self-levelling suspension system, IEE Proc. Control Theory Appl. 142 (2) (1995) 129-139, doi: 10. 1049/ip-cta: 19951776.

DOI: 10.1049/ip-cta:19951776

[6] Xiaxu Huang, Yanhua Shen, Wenming Zhang, Analysis of Articulated Dump Trucks Vibration and Rear Suspension Stiffness Sensitivity, HSAE 2010 World Congress and Exhibition, April 2010H, doi: 10. 4271/2010-01-0387.

DOI: 10.4271/2010-01-0387

[7] ISO2631-1: 1997(E), Mechanical vibration and shock - Guide for the evaluation of human exposure to whole-body vibration.
