Analysis for Obstacle Negotiation Capability of Wheel-Legged Robot

Abstract:

Obstacle negotiation capability is important to a mobile robot. A wheel-legged robot with symmetrical structure was presented It has four independent wheel-legged articulations which can generate a series of conFigureurations to improve its trafficability. The obstacle negotiation capability of the robot was studied. Its step-climbing process was described, and the geometrical and dynamic model for the process was built. Based on comprehensively considering geometrical and dynamic constraints, the method to work out the maximal step height that the robot can get across was brought forward. Then the method to work out the maximal slope angle was also provided. Finally the experiment to verify the above methods was done. The research mentioned above would provide a theoretical foundation to improve the robot’s adaptability in complicated environments.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 183-189
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.183
• Online since: November 2011
• Authors: Hai Bo Tian, Zong De Fang, Fan Jun Meng, Xiao Fang Yang
• Keywords: Dynamic, Geometrical Constraints, Mobile Robot, Obstacle Negotiation

References

[1] W Lee, S Kang, et al. ROBHAZ-DT3: Tele-operated mobile platform with passively adaptive double-track for hazardous environment applications[C]. Proc. IEEE/RSJ International Conference on Intelligent Robots and Systems(Sendai, Japan, 2004). Vol. 1, pp.33-38.

DOI: 10.1109/iros.2004.1389325

[2] T Wang, R Q Yang, et al. Posture design of joint-wheeled mobile robot autonomous negotiating singular terrain[J]. Journal of Shanghai Jiaotong University, Vol. 35(2001) No. 1, pp.59-63.

[3] J G Xin, X F Li, Z Wang, et a1. Performance analysis of track-leg mobile robot in unstructured environment[J]. Robot, Vol. 26(2004) No. 1, pp.35-39.

[4] K Iagnemma, H Shibly, et a1. Planning and control algorithms for enhanced rough-terrain rover mobility[C]. Proc. International Symposium on Artificial Intelligence and Robotics & Automation in Space(Quebec, Canada, 2001) . Vol. 1, pp.1-8.

[5] P Lamon, A Krebs, et a1．Wheel torque control for a rough terrain rover[C]. Proc. IEEE International Conference on Robotics and Automation(New Orleans, USA, 2004) . Vol. 1, pp.4682-4687.

DOI: 10.1109/robot.2004.1302456

[6] C Kim, S Yun, K Park, et al. Sensing system design and torque analysis of a haptic operated climbing robot[C]. Proc. IEEE/RSJ International Conference on Intelligent Robots and Systems(Sendai, Japan, 2004) . Vol. 1, pp.1845-1848.

DOI: 10.1109/iros.2004.1389665

[7] J G Liu, Y C Wang, S G Ma, et al. Analysis of stairs-climbing ability for a tracked reconfigurable modular robot[C]. Proc. IEEE International Workshop on Safety, Security, and Rescue Robotics(Kobe, Japan, 2005) . Vol. 1, pp.36-41.

DOI: 10.1109/ssrr.2005.1501238

[8] Y C Yu, K Yuan, W Zou. Dynamic model of all-wheel-drive mobile robot climbing over obstacles and analysis on its influential factors[J]. Robot, Vol. 30(2008) No. 1, pp.1-6.
