The Fine System-Level Calibration Technique of Size Effect Error for the Fiber-SINS

Abstract:

A fine system-level calibration technique of size effect error is presented for Fiber-strap-down inertial navigation systems (Fiber-SINS) in this paper. When the strap-down system is mounted onto high precision turntable and rotating along predefined trajectory, the velocity errors can contain information related to the size effect error, which can be estimated accurately by Kalman filter. In this paper, principles of the calibration technique are emphasized, the model of the size effect error is presented and Hardware-in-the-Loop Simulation platform is designed to validate the efficiency of this technique. Results show that the calibration technique has the advantages such as simplicity and high precision. Thus it is of great importance for practical applications.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 2060-2065
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.2060
• Online since: November 2011
• Authors: Lu Feng Zhu, Chun Xi Zhang
• Keywords: Error Model, Fiber- SINS, Fine Calibration, Kalman Filter (KF), Size Effect Error

References

[1] Zhang Kaidong, The continuous automatic calibration technology of laser gyro strapdown inertial navigation system (LSINS), Changsha Graduate School of National University of Defense, (2002).

[2] Zhang Tianguang . et. Strapdown Inertial Navigation Technololgy (2nd Edition) , Beijing National Defense Industry Press (2007).

[3] Robert M. Rogers. Applied mathematics in integrated navigation systems, AIAA, 173-183, America: American Institude of Aeronautics and Astronautics, (2003).

[4] Chen Zhe. The principle of strapdown inertial system, Beijing: Space Navigation Press, (1986).

[5] Gu Hongqiang, Yuan Yaxiong, Bai Weibing. Missile Strap-down Inertial Measuring Unit Fasr Postion Demarcation, 2007，31(6)：719-721.

[6] Mohinder S. Grewal. Application of Kalman Filtering to the calibration and alignment of inertial navigation systems,. IEEE, 1991, VOL. 36, NO. 1: 4-12.

[7] Eduardo Nebot, Hugh Durrant-Whyte. Inertial Calibration and Alignment of Low Cost Inertial Navigation Units, Journal of Robotics Systems, 1999, V1(16): 81-92.

DOI: 10.1002/(sici)1097-4563(199902)16:2<81::aid-rob2>3.0.co;2-9

[8] Xu Bo, Sun Feng. A FOG Online Calibration Research Based on High-precsion three-axis Turntable, 2009 International Asia Conference on Infornatics in Control, Automation and Robotics.

DOI: 10.1109/car.2009.48

[9] Huang Ping, Research on Calibration Technique of the Strapdown Inetial Navigation System, Harbin, Harbin Engineering University master thesis, (2005).
