Effect of Magnetic Circuit’s Structure Parameters on Torque-Speed Characteristic for Electromagnetic Damper

Abstract:

The electromagnetic damper studied in this paper belongs to a special kind of coreless generator, which is primarily used for the energy absorption and dissipation in space docking mechanism buffer system. The parameters of magnetic circuit tructure which determines the air-gap flux density are important factors in affecting damping torque. Three-dimensional models are built based on MagNet of Infolytic corporation in this paper. The effects of structure parameters of magnetic circuit such as magnet material, magnetic pole-pairs, rotor thickness on the torque-speed characteristic are researched. The analysis results show that the damping torque is proportional to the square of the amplitude of the fundamental component of the air gap flux density, rotor thickness respectively, the relationship of the torque-speed ratio with the magnetic pole is neither directly proportional nor inversely proportional.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 2038-2044
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.2038
• Online since: November 2011
• Authors: Yan Fang Wang, Lin Lin He
• Keywords: 3D Simulation, Air-Gap Gap Flux Density, Magnetic Circuit’s Structure, Torque Speed Characteristic

References

[1] KASARDA , M E F , Mendoza H KIRK R G, et al . Reduction of subsynchronous vibratio-ns in a single-diskrotor using an active magnetic damper [J]. Mechanis Research Communicatio- ns, 2004, 31 (6): 689-695.

DOI: 10.1016/j.mechrescom.2004.04.004

[2] L.H. Xu,Z.X. Li and Y. Zhou. Optimum and Simulation of Semi-active Control System Based on MRFD. Earthquake Engineering Frontiers in the New Millennium, Oct., 2001: 317-320.

DOI: 10.1201/9780203758984-46

[3] Morimasa Watakabe, Masanobu Tohdo, Osamu Chiba, Nobuyuki Izumi, Hiromichi Ebisawa and Takafumi Fujita. Response Control Performance of a Hybrid Mass Damper Applied to a Tall Building. Earthquake Engrg. Struct. Dyn. Vol. 30, 2001: 1655-1676.

DOI: 10.1002/eqe.86

[4] Ichiro Nagashima, Ryota Maseki, Yutaka Asami, Jun Hirai and Hisanori Abiru. Performance of Hybrid Mass Damper System Applied to a 36-Story High-rise Building. Earthquake Engrg. Struct. Dyn., Vol. 30, 2001: 1615-1637.

DOI: 10.1002/eqe.84

[5] DC Coreless motors, [J], 2003TELSTAR International Technology Co., Ltd/ EVERCOM Group.

[6] Sharifaddin Sharif and Kourosh Sharif, Influence of skin effect on torque of cylindrical eddy current brake, International Conference on Power Engineering, Energy and Electrical Drives, 2009, Lisbon, Portugal, 18-20 Mar., 2009, pp.535-539.

DOI: 10.1109/powereng.2009.4915143

[7] Brauer J., Schafer S., Lambert N., McNeal B., Mixing 2D with 3D Finite Elements in Magnetic Models, IEEE Transactions on Magnetics, Sep (1990).

DOI: 10.1109/20.104666

[8] Pereira G., Silva E., Fonseca A., Mesquite R., The Element-Free Galerkin Method in Three-Dimensional Electromagnetic Problems, IEEE Transactions on Magnetics, April (2006).

DOI: 10.1109/tmag.2006.872014

[9] Schinerl M., Schoberl J., Kaltenbacher M., Lerch R., Multigrid Method for Three-Dimensional Simulation of Nonlinear Magnetomechanical System, IEEE Transactions on Magnetics, May (2002).

DOI: 10.1109/20.999123

[10] Mi Chunting, M ariano Filippa, Liu Weiguo, etal. Analytical method for predicting the air-gap flux of interior-type permanent magnet machine [J ]. IEEE Transacions on Magnetics, 2004, 40 (1) : 50-58.

DOI: 10.1109/tmag.2003.821562

[11] Fujita M, Tokumasu T., Yoda H., Tsuda H., Ito K., Nagano S., Magnetic Field Analysis of Stator Core End Region of Large Turbo generators, IEEE Transactions on Magnetics, Vol. 36, No. 4, p.1850, July (2000).

DOI: 10.1109/20.877805
