A Stator Flux Estimation Method Based on Duty Cycles of Inverter Switching

Abstract:

This paper presents a stator flux estimation method based on duty cycles of inverter switching. The stator flux is calculated by integrating the back electromotive force, which is the terminal voltage minus the voltage drop on the stator resistance. The terminal voltage mentioned above is calculated by the duty cycles of inverter switching and dc link voltage, while the duty cycles is derived in the digital control system of induction motor based on the DSP. Without employing voltage sensors to measure phase voltage, the proposed flux estimation method is cost effective and error reducing. The method is also effective in fault-tolerant operation when the motor works with two phases. Experimental results verify the effectiveness of the proposed method.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 4932-4937
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.4932
• Online since: November 2011
• Authors: Yi Feng Wu, Zhi Quan Deng, Yu Wang
• Keywords: Duty Cycle, Inverter Leg State, Phase Voltage, Stator Flux

References

[1] Wu R, Slemon G R. A permanent magnet motor drive without a shaft sensors[J]. IEEE Trans. on I. A., 1991, 27(5): 1005-1011.

DOI: 10.1109/28.90359

[2] Luukko J, Niemela M, Pyrhonen J. Estimation of the flux linkage in a direct-torque-controlled drive. IEEE Transactions on Industry Applications, 2003, 50(2): 283-287.

DOI: 10.1109/tie.2003.809392

[3] Tajima H, Hori Y. Speed sensorless field oriented control of the induction machine[J]. IEEE Transactions on Industry Applications, 1993, 29(1): 175-180.

DOI: 10.1109/28.195904

[4] Maurizio Cirrincione and Marcello Pucci, A New Adaptive Integration Methodology for Estimating Flux in Induction Machine Drives, IEEE Transactions on Power Electronics, 2004, Vol. 19, No. 1, p.25~34.

DOI: 10.1109/tpel.2003.820565

[5] Yu. X, Dunnigan. M. W, Williams. B. W, Phase voltage estimation of a PWM VSI and its application to vector-controlled induction machine parameter estimation, IEEE Transactions on Industrial Electronics, 2000, 47(5): 1181-1184.

DOI: 10.1109/41.873230

[6] Cossar. C, Popescu. M, Miller. T.J. E, McGilp. M and Olaru. M, A General Magnetic-Energy-Based Torque Estimator: Validation via a Permanent-Magnet Motor Drive, IEEE Transactions on Industry Applications, 2008, Volume 44, Issue 4: 1210 – 1217.

DOI: 10.1109/tia.2008.926231

[7] S. Bolognani, M. Zordan, and M. Zigliotto. Experimental fault-tolerant control of a PMSM drive[J]. IEEETrans. Ind. Electron., vol. 47, p.1134–1141, Oct. (2000).

DOI: 10.1109/41.873223

[8] Zhu. Z. Q, Utaikaifa. K, Hoang. K, Liu. Y, Howe. D, Direct torque control of three-phase PM brushless AC motor with one phase open-circuit fault, IEEE Electric Machines and Drives Conference, 2009. IEMDC '09 : 1180 – 1187.

DOI: 10.1109/iemdc.2009.5075353
