Design of Mining Portable Static Resistance Strain Gauge Based on ATmega16L

Abstract:

Mining portable static resistance strain gauge based on ATmega16L is introduced in this paper. It is used to monitor stress of bolt support in coal mines. The strain gauge is high-precision, simple and Chinese-displaying. It offers a more portable testing method of bolt support in coal mines for the workers.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 5917-5922
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.5917
• Online since: November 2011
• Authors: Qian Sun, Feng Yi Guo, Bin Li, Fei Yin, Peng Xu
• Keywords: ATmega16L, Instrumentation Amplifier, Static Resistance Strain Gauge
