Stability Analysis of Single-Track Railway Long Span Combination Bridge of Arch and Beam

Abstract:

For the single-track railway concrete-filled steel tube tied-arch bridge, since restrictions of the bridge width will inevitably lead to a relatively smaller ratio of width to span using long span.The stability is a very prominent issue in design and construction. Taking a 136m span through concrete filled steel tube tied-arch bridge as an object, considering the influence of geometric and material nonlinearity of arch rib, its space stability analysis of the whole bridge is made using finite element program. Its stability factor and the instabil-ity mode are given under the most unfavourable load condition. Instability of the structure is mainly shown in out-plane instability of arch rib. Elastic buckling factor is greater than the general requirement, which satisfies the requirement of the bridge elastic stability. The effect of geometric nonlinearity on stability of the bridge is smaller while the effect of material nonlinearity is greater, which should be considered in the stability analysis of long span arch bridge. After the arch ribs are progressively loaded, the ultimate loads of the arch ribs are obtained. Effects and variation law of transverse brace layout, arch rib inclination angle and ratio of height to span of the arch to the stability of this bridge are revealed.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 6079-6084
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.6079
• Online since: November 2011
• Authors: Ri Chen Ji, Jun He, Ming Xing Shi
• Keywords: Concrete-Filled Steel Tube (CFST), Finite Element, Nonlinearity, Stability Analysis, Tied-Arch Bridge, Transverse Brace

References

[1] Xiang H. F. Higher Bridge Structure Theory[M]. Beijing, People's Transportation Publish, (2001).

[2] Fan J. J., Qiu W. L., Zhang Z. Analysis of Stability During Construction of Moon Island Bridge in Dandong City ,. Highway. No. 5 , (2003).

[3] Liu S. Z., Ouyang Y. J., Shen B. Analysis of the Struture Stability and Dynamic Behavior of a Steel Tube Tied-arch Bridge,. Journal of Gansu Sciences. Vol. 6, No. 1, (1994).

[4] Li G. H. Structure Stability and Vibration of Bridge[M]. Beijing, China Railway Publish, (1996).

[5] Ren Weixin, Zhao Tong, Issam E. Analysis of Steel Ar-ch Bridge". Journal of Structural Engineering, vol. 130, No. 1, (2004).

[6] Seung—Eock Kim, Se—Hyu Choi, Sang—Soo Ma. Pe-rformance Based Design of Steel Arch Bridges Using Practical Inelastic Nonlinear Analysis,. Journal of Constructional Steel Research, vol. 59;. No. 1, (2003).

DOI: 10.1016/s0143-974x(02)00019-6

[7] NAZMY A S．Stability and Load-carrying Capacity ofThree-dimensional Long-span Steel Arch Bridges,. Computers＆Structures. vol. 65, No. 6, (1997).

DOI: 10.1016/s0045-7949(97)00001-1

[8] Tan H. X., Chen Z. Q., Fen Z. Q. Stability Reseach on Hybrid Bridge of Rigid Frame and Single Arch Rib ,. Journal of Vibration and Shock. vol. 27, pp.122-125, No. 12, (2008).

[9] Wu S. J., Zhen Z. F. Finite Element Analysis of Long Span Concrete-filled Steel Tube Arch Bridge Lateral Stability ,. East China Highway. pp.23-26, No. 6 , (1996).

[10] Pan S. S., Zhang Z., Huang C. L. Research on Laeral Stability Influenced by inclined angle of through X-type Double Ribs Arch Bridge ,. Journal of Dalian University of Technology. Vol. 48, pp.845-850, No. 6Nov. (2008).
