Design of Random Combination System Based on Five Common Kinds of Mechanical Transmission

Abstract:

Introduce system’s overall function design concept and key technologies. The system is divided into driving module and driven module. According to the depth of calling, the system can also divide into four application modules, and is developed in coordination with Visual Basic 6.0, Visual FoxPro 6.0 and Visual LISP. Each module uses Windows and AutoCAD as executive support system. Under the control of interface program, the module can automatically execute and transmit data. Focus on the program interface design of the driving module. Users can be allowed to arrange and combine five common types of mechanical transmission. 3905 kinds of transmission scheme that is less than five levels can be got. The system can finish total design computation, work capability computation, tolerance database inquiry and drive part drawing drafting automatically and continuously. Mechanical design efficiency can be greatly improved.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 7475-7479
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.7475
• Online since: November 2011
• Authors: Ru Ming Qin
• Keywords: Common Mechanical Transmission, Development Technology, Mechanical CAD, Random Combination

References

[1] Ruming Qin. Mechanical CAD. Xidian University Press, Xian, 2005(In Chinese).

[2] Ruming Qin. Parameterized Mechanical Design. China Machine Press, Beijing, 2009(In Chinese).

[3] Huaiming Li. Visual Basic Reference Detailed Annotation[M]. Tsinghua University Press, Beijing, 1999(In Chinese).

[4] Haoqiang Tan. QBASIC Program Design[M]. Tsinghua University Press, Beijing, 2000(In Chinese).

[5] Kunshen Zhang. API for Windwos98/2000 Detailed Annotation[M]. Tsinghua University Press, Beijing, 2001(In Chinese).
