Starting Performance of Novel Magnet Arrayed Permanent Magnet Synchronous Motor

Abstract:

In order to improve the sinusoidal level of air gap magnetic field of the traditional surface PMSM, reduce its harmonic losses and fully reflect its energy-saving advantages, this paper introduces a type of sinusoidal pole width modulation permanent magnet synchronous motor. The surface magnetic poles of the rotor iron core constitute by a number of small array magnets, which makes the air gap magnetic field more sinusoidal. Placing starting winding in remaining space between array magnets of rotor outer surface to make surface-mounted permanent magnet synchronous motor add self-starting function. The sine wave distortion rate of air gap magnetic field of sinusoidal pole width modulation structure was compared with traditional surface-mounted structure by electromagnetic field calculation and experiment. The copper starting winding and aluminum starting winding were placed in sinusoidal pole width modulation structure motor respectively, and then the paper analyzes dynamic torque and rotational speed of self-starting progress. Finally the analysis is verified by experiments.

• Periodical: Advanced Materials Research (Volumes 383-390)
• Pages: 835-839
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.383-390.835
• Online since: November 2011
• Authors: Yue Jun An, Hong Liang Wen, Wen Qiang Zhao, Guo Ming Liu, Zhao Jun Meng
• Keywords: Finite Element Analysis (FEA), Permanent Magnet Synchronous Motor (PMSM), Pole Width Modulation, Self-Starting, Surface Mounted Type

References

[1] Renyuan Tang Modern permanent magnet machines theory and design Beijing, [M]: Machinery Industry Press.

[2] Guoqiang Song; Chaohui Zhao Study of Halbach Array PM Machines, [J] Electric Machines & Control Application; 2008(07).

[3] Yanliang Xu Fuan Yao Jiancheng Fang Halbach Array Permanent Magnet Machine and Its Performance Comparison with the Normal Array One(II) — Comparison of Different Magnet Array Ironless Machine and Prototype Experiment, [J] Transactions of China Electrotechnical Society. 2004(06).

DOI: 10.1109/ipemc.2006.297377

[4] Yuejun An, Changzhi Sun. A type of Pole Width Modulation Method of PMSM. China,: CN200720015431[P], (2007).

[5] Yuejun An, Peng Wang, Zhaojun Meng, et al. Pole Width Modulation Method of PMSM and Its Magnetic Field Analysis,. ICACC 2010, 27-29 March 2010, Shenyang/China, 376-380.

DOI: 10.1109/icacc.2010.5486995

[6] Peng Wang Pole Width Modulation Method of Line-start PMSM and its Magnetic Field Analysis, [D] Shenyang University of Technology. (2009).
