Test Study on Creep Character of Anchor Rod in Argillaceous Soft Rock

Abstract:

The creep character of anchor rod in argillaceous soft rock is remarkable. The big undisturbed mudstone samples in Nanning Basin as a typical argillaceous soft rock is chosen to the research object in this paper. The laboratory simulated destructive tests and the creep tests of full grouted anchor rod have been down. Through the destructive tests of mudstone sample, the instantaneous adhesive strength between the anchor body and mudstone in Nanning Basin is 70kPa. By analyzing the creep curves of anchor rod, a conclusion is that there is a long-term adhesive strength of anchor rod in argillaceous soft rock. When the design adhesive strength of anchor rod is less than the long-term adhesive strength, eventually the anchor rod is stable during the process of long-term pull-out. When the design adhesive strength of anchor rod is greater than the value, the creep of anchor rod with the time will do not stop until the anchor rod failure. The greater difference value between the instantaneous and long-term adhesive strength, the faster the rate of creep, the faster the anchor rod failure. Finally, for the permanent support engineering design of anchor rod in argillaceous soft rock, the paper gives two principles, as follows: (1) the design of anchor rod in argillaceous soft rock must be determined according to the long-term adhesive strength. (2) by using variety of technical measures, the impact of various factors on the creep of anchor rod will be decreased.

• Periodical: Advanced Materials Research (Volumes 396-398)
• Pages: 565-570
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.396-398.565
• Online since: November 2011
• Authors: Qiu Yan Fan, Cai Lin Liu, Ke Qing Yang, Mei Qian Wang
• Keywords: Anchor Rod, Argillaceous Soft Rock, Creep, Long-Term Adhesive Strength

References

[1] FAN Qiuyan.Expansive Rock and Engineering[M]. Beijing:Science Press,2008.(in Chinese)

[2] XU Hong-fa, LU Hong-biao, QIAN Qi-hu. Creep Damage Effects of Pulling Grouting anchor Soil[J]. Chinese Journal of Geotechnical Engineering 2002,24(1): 61-63.(in Chinese)

[3] Chen Wei-hua, LI Sheng-jun, ZHU Fan-qing, et al. The Test study and bearing force analysis of the prestress bolt in modification works of Haihe embankment [J].Haihe Water Resources,2008, (3):53-55.(in Chinese)

[4] YUAN Feng, WANG Li-xiang, ZHAO Wei-chen, et al. The Test study on bearing character and Construction of jet grouting bolt[J]. Building Construction, 2008, 30(10):851-854. (in Chinese)

[5] CHEN Anmin, GU Jincai, SHEN Jun, et al. Model Testing research on the variation of tension force of anchor cable with time In reinforcement of soft rocks [J]. Chinese Journal of Rock Mechanics and Engineering, 2002,21(2):251-256.(in Chinese)

[6] WU Guojun. Time-Dependent Behaviour of Rock Mass and Its Reliability on Anchoring in Underground Engineering[D]. Wuhan:Institute of Rock and Soil Mechanics, Chinese Academy of Sciences, 2009.(in Chinese)

[7] FAN Qiuyan, CHEN Bo, SHEN Bing. Model test research of bolt supporting of foundation pit considering construction process[J]. Rock and Soil Mechanics, 2005, 26(12): 1874-1878. (in Chinese)
