The Design of Wireless Detection and Remote Management System of Thermal Defects

Abstract:

A wireless detection and remote management system is designed to solve the problem of Real-Time wireless detection of thermal defects of high voltage equipment. This system uses a new method that continuous power of CC2530, a ZigBee wireless single chip, is provided by using monocrystalline silicon solar cells and thermoelectric generation modules. This method can also solve the problem that overheat faults cannot be alarmed timely when efficiency of solar cells decrease during the continuous rainy days, and can realize Real-Time wireless detection and remote fault analysis of thermal defects of high voltage equipment. The supervisory programs of the remote PC and the upper computer are designed through VC + +.NET and the communication mode adopts C/S model based on TCP/IP protocols. The image files are saved as JPEG format by CImage class, which implements the real-time transmission of images. All of these provide a technical assurance to the remote and intelligent control of heat vice of high-voltage equipment in multi-stations.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 2410-2414
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.2410
• Online since: November 2011
• Authors: Jun Hua Xiong, Hao Hu
• Keywords: Remote Management System, Solar Cell, Thermal Defect, Thermoelectric Generation Module, Wireless Detection

References

[1] Zhenting Lv, Jian Cao, in: Electronic Measurement Technology, vol. 31( 2008), pp.191-193.

[2] Xuesheng Liu, Pengfei Shi, Jun Lv, et al., in: Chinese Joural of Power Sources, vol. 30(2006), pp.193-195.

[3] Zhian Lv: The principle and application development of ZigBee network( Beihang University Press, Beijing 2008).

[4] Yulan Lin, Yingyang Lv, in: Chinese Joural of Power Sources, vol. 30(2006), pp.39-40.

[5] Wenzhong Li, Chaoyu Duan: Threshold and Practice of ZigBee Wireless Network Technology(Beihang University Press, Beijing 2007).

[6] Wei He: Visual C + +. NET2003 program design(Metallurgical Industry Press, Beijing 2004).

[7] Tingting Li, Tengfei Bao, in: Journal of Hydroelectric Engineering, vol. 10(2005), pp.118-123.
