The Research of Virtual Design and Parts Library System Oriented to High Voltage Switchgear

Abstract:

In this paper, a standardized method of virtual design for high voltage switchgear based on Inventor has been investigated. A multi-attribute and multi-method parts library system also has been designed and developed which was integrated seamlessly with the three-dimensional design software. This investigation can achieve visualization design for large-scale product, and effective management, integration and sharing for 3D models and design information. The design efficiency and the information level of the enterprise can be greatly improved, and the product development cycle can be greatly shorten.
