Influence of Addition the Al Power on the Tensile Shear Loads in Resistance Spot Welding of TC4/AZ31B

Abstract:

The tensile shear loads in resistance spot welding of TC4/AZ31B with addition Al power have been investigated in this paper. The results showed that the tensile shear loads with and without addition Al power were 2.636 KN and 3.692 KN when welding current was 9800A , respectivly. And the values changed 2.971 KN and 4.167 KN when the welding current was 11300A, respectively. Morphology characteristics of the welding zone were studied by scanning electron microscopy (SEM), energy dispersive spectrometer (ESD). The results suggested that the addition of Al power on the sheets of TC4 and AZ31B increased much in the tensile-shear loads when welding TC4 and AZ31B by RSW.

• Periodical: Advanced Materials Research (Volumes 403-408)
• Pages: 4351-4354
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.403-408.4351
• Online since: November 2011
• Authors: Xin Bin Hu, Zhang Qiang Mei, Li Qun Li, Ping Luo, Shi Jie Dong
• Keywords: AZ31B, Resistance Spot Welding (RSW), TC4

References

[1] Xiong Jiangtao et al. Transient Liquid Phase Bonding of Magnesium Alloy (AZ31B) and Titanium Alloy (Ti6Al4V) Using Aluminium Interlayer[J], Rare Metal Materials and Engineering, 2006, Vol. 35, No. 10; 1677(in Chinese).

[2] Barreda JL, Santamaría F, Azpiroz X, Irisarri AM, Varona JM. Vacuum 2001; 62(2-3): 143–50.

[3] Kahraman N. Joint of titanium plates to different metals by explosive welding method and investigation of their interface properties. Ph.D. Thesis, Gazi University, Ankara-Turkey, (2003).

[4] Kahraman N. Joint of titanium plates to different metals by explosive welding method and investigation of their interface properties. Ph.D. Thesis, Gazi University, Ankara-Turkey, (2003).

[5] Masayuki Aonuma, Kazuhiro Nakata. Effect of alloying elements on interface microstructure of Mg-Al-Zn magnesium alloy and titanuim joint by friction stir welding[J]. Materials Science and Engineering B 161(2009): 46.

DOI: 10.1016/j.mseb.2009.02.020

[6] Ranfeng Qiu. Development of New Resistance Spot Welding for Similar and Dissimilar Material Joints of Lightweight Metals: 113-114.

[7] Stern A, Munitz A (1999) J Mater Sci Lett 18: 853.

[8] Weisheit A, Galun R, Mordike BL (1998) Weld J 77: 149-s.

[9] Marya M, Edwards GR, Marya SK, Olson DL (2001).

[10] Zhao H, Devroy T (2001) Weld J 80: 204-s.

[11] ASM International (1993) Welding, brazing and soldering. ASM handbook, vol 6. Materials Park, Ohio.

[12] L. Liu, S.Q. Zhou, Y.H. Tian, J.C. Feng, J.P. Jung, and Y. Zhou: Sci. Technol. Weld. Join, 2009, vol. 14: 356-61.
