Deformation and Heat Transfer Analysis for High Speed Dieless Drawing of AZ31 Magnesium Alloy Tubes

Abstract:

The effect of drawing speed and heating length on deformation behavior was investigated by numerical approach for AZ31 magnesium alloy tubes to realize high speed dieless drawing process. The length of deformation zone expands with increasing the feeding speed. The increase in heating length leads to expanding length of deformation zone. The mean strain rate increases with increasing the feeding speed firstly, and then rate of increase in the strain rate becomes gradual under condition of any length of heating band. Based on these results, a limiting reduction in area of 52.5% under higher speed and larger heating length conditions can be realized experimentally.
