Microstructure Evolution and Numerical Simulation of DP Steel TWBs During Warm Tensile Deformation

Abstract:

The tensile tests of DP590 dual-phase steel tailor-welded blanks were carried out at different temperatures and strain rates. Quantitative analysis of metallographic was utilized to study the microstructure evolution of the base metal area and the weld zone of the tensile fracture. By combining the microstructure evolution model with the secondary development technologies of ABAQUS, the microstructure evolution of dual-phase steel tailor-welded blanks was simulated during warm tensile tests. The results show that, with the temperature increasing and strain rate decreasing, the dynamic recrystallization volume fraction of ferrite increases, and the martensite transform into equiaxed ferrite gradually. The results of microstructure simulation are in good agreement with experimental results.

• Periodical: Advanced Materials Research (Volumes 418-420)
• Pages: 1222-1227
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.418-420.1222
• Online since: December 2011
• Authors: Lu You Yue, Zhong Fu Huang, Zhen Liang He, Man Guo Jiang, Wei Chen
• Keywords: Dual Phase Steel, Micro-Structure Evolution, Numerical Simulation, Tailor Welded Blanks

References

[1] W. Chen, Z. G. Peng, B. Hou, J. W. Bei, and H. Y. Feng: Theoretical establishment of forming limit diagram for laser tailor-welded blanks. Journal of mechanical engineering, Vol. 45 (4) (2009), p.183.

DOI: 10.3901/jme.2009.04.183

[2] M. Naderi, M. Ketabchi, and M. Abbasi: Analysis of microstructure and mechanical properties of different high strength carbon steels after hot stamping. Journal of Materials Processing Technology, Vol. 211 (6) (2011), p.1117.

DOI: 10.1016/j.jmatprotec.2011.01.015

[3] P. Li, K. M. Xue, and Y. Lv: Influence and prediction of heat forming parameters on the microstructure of Ti-15-3 alloy. Acta metallurgica sinica, Vol. 48 (2) (2002), pp.145-148.

[4] M. Q. Li, D. J. Chen, and A. M. Xiong: An Adaptive Prediction Model of Grain Size for the Forging of Ti-6Al-4VAlloy Based on Fuzzy Neural Net works. Journal of Materials Technology, Vol. 123 (2002), p.377.

DOI: 10.1016/s0924-0136(02)00040-7

[5] W. B. Deng, H. Q. Chen, and Z. X. Li: Microstructure Simulation of TC11 Titanium Alloy During Disk Forging Processes. Journal of materials engineering, Vol. 12 (2009), p.30.

[6] Z. Tang, H. Yang. Z. C. Sun, Z. Y. Li, and H. Dun: Microstructure evolution and numerical simulation of TAl5 titanium alloy during hot compressive deformation. The Chinese Journal of nonferrous metals, Vol. 4 (18) (2008), p.722.

[7] W. Chen, L. Xue, and K. M. Chen: Warm Tensile Properties and Microstructures of Dual Phase Steel Laser Tailor Welded Blanks. Journal of materials engineering, Vol. 7 (2010), p.54.

DOI: 10.3901/jme.2011.22.049

[8] Z. C. Sun, H. Yang, and X. Z. Ou: Effects of process parameters on microstructural evolution during hot ring rolling of AISI 5140 steel. Computational Materials Science, Vol. 49 (2010), p.134.

DOI: 10.1016/j.commatsci.2010.04.036

[9] C. Zener, and H. Hollomon: Effect of strain-rate upon the plastic flow of steel. J Appl Phys, Vol. 15 (1) (1944), p.22.

DOI: 10.1063/1.1707363

[10] W. Chen, L. Xue, S. Chen, G. Y. Teng, and M. Y. Wu: The flow stress model of dual phase steel laser tailor welded banks during warm tension. Journal of functional materials, Vol. 40 (12) (2009), p.183.
