Study and Design of Human-Machine Interface System for Embedded CNC Precision Internal Grinder

Abstract:

According to the properties of the CNC precision internal grinding, the Human-machine interface system for the CNC based on industrial-grade touch device is proposed in this paper. Based on analyzing the human-machine interface system on the whole, each module is described in detail. The whole human-machine interface system is friendly, convenient and flexible, which meet the function requirements of embedded CNC precision internal grinder.
