Parameters Optimization and Theoretical Analysis on Duckbill-Type Device for Sugar Beet Paper Pot Seedling Transplanting

Abstract:

The transplanting device is the key component of a sugar beet paper pot seedling transplanting machine. The parallel four-bar framework is composed of active and passive disc, connecting rod and the duckbill-type linkage, which could ensure duckbill-type device always moving perpendicular to the ground, and its trajectory is trochoid. When the device rotated to near the lowest position, the duckbill’s absolute speed is close to zero, at this time the paper pot seedlings were given out to drop into the trench smoothly through opening the beak, while the role of duckbill transfered from loading to helping the paper pot seedlings to avoid dumping, and the planting process is finished through earth up and suppression. The parameters of a duckbill-type transplanting device are obtained through optimization and simulation, which could meet the requirements of duckbill-type device for transplanting paper pot seedling of sugar beet.

• Periodical: Advanced Materials Research (Volumes 418-420)
• Pages: 2065-2069
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.418-420.2065
• Online since: December 2011
• Authors: Bing Fu Lu, Ji Yang
• Keywords: Paper Tube Seedling, Sugar Beet, Transplanting Device

References

[1] Zuowei Zhao, Haitao Chen, Qinghui Lai et al. Transactions of the Chinese Society of Agricultural Engineering. 26(2010)154-157 (In Chinese)

[2] Yubao Nian. Sugar Crops of China. 2,( 2004)32-35 (In Chinese)

[3] Ji Yang, Bingjin Han. Sugar Crops of China. 4 (2010)83-86 (In Chinese)

[4] Bingfu Lu, Ji Yang. Sugar Crops of China. 3 (2011) 68-70 (In Chinese)

[5] Litao Wang, Shengxue Zhao, Hongying Teng. Xinjiang Agricultural Mechanization, 1 (2009)22-23 (In Chinese)

[6] Wenming Wang，Weiguo Dou，Chunguang Wang et al. Transactions of the Chinese Society for Agricultural Machinery.40（2009）69-73 (In Chinese)

[7] Qiyun Li, Shanwen Lu, Lihua Li. Transactions of the Chinese Society for Agricultural Machinery.32(2001)30-33 (In Chinese)

[8] Aihua Li, Yanfei Jiang, Hongzhang Wang. Mechanization in Rural & Pastoral Areas, 3 (2007)11 (In Chinese)

[9] Deyi Zhou, Yujing Sun, Chenglin Ma. Transactions of the Chinese Society for Agricultural Machinery.34( 2003)58-60 (In Chinese)
