Simulation on Anode Electric Field Intensity about Electrochemical Jet Machining

Abstract:

The theory of electrochemical jet machining was introduced, and effect of different parameters on anodic electric field intensity is finite element analyzed by ANSYS software. The Simulation results show that, the electric field shares the same distribution under different electrolysis voltage, which generally contains three parts, uniform distribution area, gradually weakened area, scattered area. In the uniform distribution area, electric field shows comparative uniformity. The anode electric field generated by different jet distance is also obvious distribution areas, the electric field intensity shows decreasing trend. Electric field intensity is found to have a close relationship with electro jet nozzle diameter, in which a faster jet velocity would bring more concentrated distribution of the electric field as well as a smaller size of electric field.

• Periodical: Advanced Materials Research (Volumes 418-420)
• Pages: 2046-2049
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.418-420.2046
• Online since: December 2011
• Authors: Cheng Guang Zhang, Fei Hu Zhang, Cheng Guang Zhang
• Keywords: Electric Field, Electrochemical Jet Machining(ECJM), Electrolysis Voltage, Jet Distance, Jet Nozzle Diameter

References

[1] M.S. Ahmed, A. Duffield. The drilling of small deep holes by acid ECM, Proceedings Advanced Machining Technology III Conference, Chicago, Illinois, Sep. 4-6, 1990 pp.1-13.

[2] G.E. Baker. Hole drilling processes: experiences, applications, and selections, Proceedings SME Nontraditional Machining Symposium, Orlando, Florida, 3rd–5th Nov., 1991 pp.1-12.

[3] G. Bellows, J.B. Kohls. Drilling without drills, American Machinist, Special Report 743 (1982) 173-188.

[4] M. Sen, H.S. Shan. A review of electrochemical macro to micro hole drilling processes, International Journal of Machine Tools and Manufacture 45 (2) (2005) 137-152.

DOI: 10.1016/j.ijmachtools.2004.08.005

[5] M. Sen, H.S. Shan. Analysis of hole quality characteristics in the electro jet drilling process. International Journal of Machine Tools & Manufacture 45 (2005) 1706-1716.

DOI: 10.1016/j.ijmachtools.2005.03.005

[6] Mohan Sen, H.S. Shan. Electro jet drilling using hybrid NNGA approach. Robotics and Computer-Integrated Manufacturing 23 (2007) 17-24.

DOI: 10.1016/j.rcim.2005.08.004

[7] Mohan Sen, H. S. Shan. Response surface analysis of electro jet drilled holes. Int J Adv Manuf Technol (2006) 31: 520-527.

DOI: 10.1007/s00170-005-0196-5

[8] CHEN jin-song, HUANG Yin-hui, TIAN Zong-jun. Simulation for cathodic electric field intensity about jet electroforming. Electroplating and Pollution Control (2009) 29:5-8.(In Chinese)
