Contact Performance Study of Modified Spur Bevel Gear Considering Assembly Error

Abstract:

By modifying the profile of spur bevel gear，the load fluctuation in transmission process can be effectively reduced, the contact area of the gear pair can be greatly improved, and the stress distribution of gear teeth also can be controlled. However, during the actual work, many factors may influence gear work performance. This paper considers the influence of assembly error on contact performance of gear in mesh, builds the assembly error mathematical model of modified spur bevel gear, and deduces the parameter equation of modified tooth profile curve. Then dynamic contact simulation analysis is carried out by applying ANSYS/ LS-DYNA software, the distribution of the stress and strain of bevel gear pair in different shaft angle deviations is accurately obtained.

• Periodical: Advanced Materials Research (Volume 421)
• Pages: 102-106
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.421.102
• Online since: December 2011
• Authors: Peng Fei Xu, Xi Jie Tian, Huan Yong Cui
• Keywords: Assembly Errors, Modified Spur Bevel Gear, Simulation Analysis

References

[1] ZH. M. Song. Mechanical Management &Development Vol.86(5)(2005),pp.18-20(In Chinese)

[2] M. A. Zhang: Cylindrical gear accuracy(China Standard Press China2002)

[3] CH. K. Zhu, X. S. Ceng. Machine Tool &Hydraulics Vol.35(4)(2007),pp.5-8(In Chinese)

[4] J. Lin: Meshing angle of conjugate curve(China Science Press China2005)

[5] W. X. Liu: Bevel gear and hypoid gear (China Communications Press, China1980)

[6] ZH. X. Sun, W. B. Li. Mechanical Engineering&AutomationVol.162(5)(2010),pp.41-43(In Chinese)

[7] D. Yang, H. Y. Cui ,X. J. Tian. The Open Mechanical Engineering Vol.(5)(2011),pp.68-77(In Chinese)
