Optional Design Research of a Composite Wing Based on Sensitivity Analysis

Abstract:

The popular finite element packages can quite well provide the structural behaviors for a given model, but the optimal design technology based on FEM is not so mature for large structures for lacking perfect sensitivity analysis. The optional design of a composite wing is accomplished by implanting semi-analytical sensitivity analysis technology into ANSYS. The structure total mass is reduced about 24%. The optimum solution not only satisfies all the restrictions, but also exhibits more uniform strain distribution. The workload of coding is reduced distinctly by this method, and the research is focused on the more important aspect of sensitivity analysis, which is useful in the engineering problems.

• Periodical: Advanced Materials Research (Volume 421)
• Pages: 687-692
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.421.687
• Online since: December 2011
• Authors: Long Yi, Hou Quan Hong, Yu Liang Li
• Keywords: Design Sensitivity Analysis, Finite Difference Method (FDM), Finite Element Method (FEM), Optimal Design

References

[1] S. Omprakash, B. M. Sameer, M. A. Mostafa: Stacking sequence design of laminated composite plates for maximum flutter velocity and buckling capacity with stability constraint. AIAA-2005-2107.

DOI: 10.2514/6.2005-2107

[2] K. K. Choi, J. T. L. Santos, M. C. Frederick: ASME Journal of Mechanism. Vol.109 (1987), pp.385-391.

[3] J. S. Arora, J. E. B. Cardoso: Computers & Structures. Vol.32 (1989), pp.691-705.

[4] W. H. Zhang, M. Domaszewski: Recent developments of sizing optimization with ABAQUS code. AIAA-98-4710.

[5] H. L. Tea, H. Y. Jung, U. L. Min: Refined semi-analytical design sensitivity analysis with commercial finite element package. AIAA-2004-4534.

[6] R. T. Haftka, H. M. Adelman: Structural Optimization. Vol.1 (1989), pp.137-151.

[7] K. F. Van, B. H. De: International Journal for Numerical Methods in Engineering. Vol.42 (1998), pp.71-91.

[8] K. F. Van, B. H. De: International Journal Solids and Structures. Vol.37 (2000), pp.6961-6980.

[9] G. J. Park: Computers & Structures. Vol.47 (1993), pp.1057-063 .

[10] W. L. Kwang, J. P. Gyung: Compufers & Structures. Vol.63, No.6 (1997), pp.1139-148.

[11] P. M. Rezaiee, M. R. Salary: Computers & Structures. Vol.61, No.3 (1996), pp.63-571.

[12] B. H. De, K. F. Van: Structural Optimization. Vol.14 (1997), pp.242-247.

[13] E. J. Parente, L. E. Vaz: International Journal for Numerical Methods in Engineering. Vol.50 (2001), 2127-2 142.

[14] R. T. Haftka, Z. Gurdal: Elements of structural optimization (Kluwer Academic Publication, Netherlands 1992).
