Real-Time Visual Analyses on Failure Criteria of Slope Stability in Strength Reduction Finite Element Method

Abstract:

The failure criteria in strength reduction FEM are not unified and often affected greatly by researcher’s experience and judgment, so it is necessary to discuss the applicability and the difference of some various criteria of instability of slope. According to the thought of visualization in real time computing, the corresponding visual program is developed based on some common failure criteria adopted simultaneity in the strength reduction FEM. Then, through the real-time visual interface, the comparisons of the common failure criteria are conducted. The results show that, the safety factor of a simple slope can be determined clearly from the inflection point of the computational curve based on the criterion of the characteristic nodal displacement and the criterion of equivalent plastic strain exceeding a certain value, by contrast, the safety factor which based on the criterion of the iteration non-convergence lag behind the others in the same condition.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1155-1158
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1155
• Online since: January 2012
• Authors: Rong Jian Li, Wen Zheng, Jun Ding Liu, Tao Xie
• Keywords: Failure Criterion, Slope, Strength Reduction FEM, Visual Analyses

References

[1] Zienkiewicz OC, Humpheson C, Lewis RW: Associated and nonassociated visco-plasticity and plasticity in soil mechanics. Geotechnique, vol. 25(1975), issue. 4, pp.691-689.

DOI: 10.1680/geot.1975.25.4.671

[2] Ugai K: A method of calculation of total factor of safety of slopes by elasto-plastic FEM. Soils and Foundations, vol. 29(1989), issue. 2, pp.190-195.

DOI: 10.3208/sandf1972.29.2_190

[3] Griffths DV, Lane PA: Slope stability analysis by finite elements. Geotechnique, vol. 49(1999), issue. 4, pp.387-403.

[4] LIU Jinlong, LUAN Maotian, ZHAO Shaofei etal: Discussion on criteria for evaluating stability of slope in elastoplastic FEM based on shear strength reduction technique. Rock and Soil Mechanics, vol. 8(2005), issue. 6, pp.1345-1348. ( in Chinese).

[5] WAN Shaoshi, NIAN Tingkai, JIANG Jingcai etal: Discussion on several issues in slope stability analysis based on shear strength reduction finite element methods (SSR-FEM). Rock and Soil Mechanics, vol. 31(2010).
