Finite Element Optimization Design of the Movable Jaw on PC5282 Jaw Crusher

Abstract:

According to the performance parameters of the main structure of the jaw crusher PC5282, movement simulation of its mechanism was done to get trajectory and the stress analysis. The three-dimensional model of the movable jaw was set up. On the COSMOSWORKS platform, finite element analysis of the movable jaw was finished to reveal the distribution laws of stress, displacement and deformation. The structure optimization of the movable jaw was also done to lighten the weight. All research was to provide references for improvement design of the movable jaw.

• Periodical: Advanced Materials Research (Volumes 430-432)
• Pages: 1614-1618
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.430-432.1614
• Online since: January 2012
• Authors: Nian Qin Guo, Wei Ping Huang
• Keywords: Finite Element Analysis (FEA), Movable Jaw, Optimization Design, PC5282 Jaw Crusher

References

[1] Xuefeng Fu, Structure and performance of the C series jaw crusher, Mining machinery, Vol . 15(2008), pp.91-94.

[2] Enpu Zhou, Mining machinery, the metallurgical industry press, Beijing, 1979, pp.17-29.

[3] Renxi Hu, Hongsong Zhang, Changli Liu, Engineering practice of the mechanical design in solidworks, Science press, Beijing, 2007, pp.12-29.

[4] Wenliang Zhu, Pingbo Wu, Strength analysis of parts in COSMOSWorks, Computer application technology, Vol . 12(2007), pp.39-41.

[5] Jianwei, Guo, the application of COSMOSWorks in parts' design, Industrial technology Vol. 30(2008), pp.71-72.

[6] Lingrong Ding, Nianqin Guo, Finite element optimization design and analysis of the adjusting seat of the jaw crusher, Coal mine machinery, Vol. 09 ( 2005), pp.23-25.
