The Finite Element Simulation Used in Straight Tooth Bevel Gear’s Vibration Rotary Forging

Abstract:

Vibration rotary forging is a complex precision forming process. In the forming process, the addition of the vibration make the boundary condition and the friction condition of the gear blank and the mould changed with the rotation of the head, which lead the forming process of the spur bevel gears become more complicated. Using the rigid-plastic finite element method to study the metal flow law and the stress distribution of the gear blank during the forming process of the spur bevel gears. Using the DEFORM-3D finite element analysis software to simulate and analysis the forming process of the spur bevel gear, in order to get the forming law of the bevel gear during the different type of the vibration parameters.
