Simulation Analysis on Sucking Process Outflow Phenomenon in Piezoelectric Pump

Abstract:

: The author has found the sucking process outflow phenomenon existing in piezoelectric pump during the outflow experiment. To explain the reason of outflow in sucking process, the fluid-structure interaction model of piezoelectric vibrator, fluid and check valve is founded. The simulation analysis turns out that the pump chamber pressure increases sharply in the later of sucking process because of the flow inertia, which is the root cause of sucking process outflow. The output flow should include two part, bulk flow and inertial flow, which will provide theoretical reference to piezoelectric pump outflow control.

• Periodical: Advanced Materials Research (Volumes 443-444)
• Pages: 1096-1100
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.443-444.1096
• Online since: January 2012
• Authors: Yong Liu, Zhi Gang Yang, Yue Wu
• Keywords: Fluid Structure Interaction (FSI), Inertial Flow, Piezoelectric Pump, Sucking Process Outflow

References

[1] KAN J W, CAO R Q, YANG Z G. Structure design and performance analysis of a piezoelectric pump [J]. Optics and Precision Engineering, 2002, 24(5): 368-371. (in Chinese).

[2] KAN J W, YANG Z G, HUA S M, CHENG G M. Study on performance of a check-valved piezoelectric pump [J]. Transactions of the Chinese Society of Agricultural Machinery, 2003, 34(5): 84-87. (in Chinese).

[3] CHENG G M, YANG Z G, ZENG P. Research on the cavity volume fluctuations of piezoelectric pump [J]. Piezoelectrics & Acorstooptics, 1998, 20(6): 389-392. (in Chinese).

[4] LIU G J, CHENG G M, YANG Z G. Experimental research on a piezoelectric micro-pump for precision pumping[J]. Optics and Precision Engineering, 2006，14(4): 612-616.

[5] SPENCER W J, WAYNE T, CORBETT L R. An electronically controlled piezoelectric insulin pump and valves[J]. Transactions on Sonics and Ultrasonics, 1978, 25(3): 153-156.

DOI: 10.1109/t-su.1978.31006

[6] KAN J W, YANG Z G, TANG K H. Pumping performance of a new piezoelectric pump for drug delivery[J]. Journal of Biomedical Engineering, 2004, 21(2): 297-301.

[7] E. John Finnemore, Joseph B. Franzini. Fluid mechanics with engineering applications[M]. Beijing：China Machine Press.

[8] Liu Y, Yang Z G, Wu Y. Inertial Flow Phenomenon Analysis on Piezoelectric Pump, edited by ICMAE, in press.
