Study on 3D Modeling for History Building and Precision Analyzing

Abstract:

Taking a certain history building as an example, we introduce a real 3D digital method for Large-Scale history building using 3D laser scanner and total station, and analyze the precision of coordinate conversion model and established 3D model. Firstly, the building are separated into many stations which are scanned separately in order to get the points cloud of each station, at the same time, the coordinates of targets and feature points of each station are obtained with laser scanner and total station respectively; next step, we convert the points cloud of every station with conversion program developed by Matlab so that the data are under the uniform reference frame with the collected homonymy targets; finally, the points cloud which have been registered are meshed in order to build real 3D digital history building model, meanwhile we analyze the precision of conversion model and the real 3D model. The result shows that this method is fast, efficient, and the prospective model has high precision.

• Periodical: Advanced Materials Research (Volumes 443-444)
• Pages: 471-476
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.443-444.471
• Online since: January 2012
• Authors: Hong Fei Zhang, Xiao Jun Cheng, Yin Tao Shi
• Keywords: 3D Model, Digital Method, History Building, Precision, Terrestrial Laser Scan

References

[1] LUO De-an, ZHU Guang, and LU Li, Whole Object Deformation Monitoring Based on 3D Laser Scanning Technology, Bulletin of Surveying and Mapping, July. 2005, pp.40-42, dio: CNKI: SUN: CHTB. 0. 2005-07-010.

[2] LI Bi-jun, FANG Zhi-xiang, REN Juan, Extraction of Building's Feature from Laser Scanning Data, Editorial Board of Geomatics and Information Science of Wuhan University, Vol. 28, Feb. 2003, pp.65-70, doi: CNKI: SUN: WHCH. 0. 2003-01-013.

[3] ZHU Ling, Research on the target in TLS, Laser Journal, Vol. 29, Jan. 2008, pp.33-35, doi: CNKI: SUN: JGZZ. 0. 2008-01-019.

[4] Linsen L. CS, Technical Report 2001-3, Point cloud representation, University at Karlsruhe, Germany, unpublished.

[5] GUANG Yun-lan, Research on Data Processing of Terrestrial Laser Scanning, shanghai: Tongji University, (2009).

[6] SHI Gui-gang, Research on Terrestrial 3D Laser Scanning Data Processing Technology and Operation Method, Shanghai: Tongji University, (2009).

[7] XIE Rui, HU Mi-jie, CHENG Xiao-jun, Study on Point Precision of 3D Laser Scanning Based on HDS3000, Remote Sensing Information, Dec. 2008, pp.53-57, doi: CNKI: SUN: YGXX. 0. 2008-06-013.
