Study on the Influence of Beam Rigidity on Continuous Rigid Frame Bridge with Moving Vehicle

Abstract:

The continuous rigid frame bridge has been applied widely in our country. But in recent years, over-deflection of beam in this bridge has become an serious problem. This may cause the redistribution of displacement and internal force of the whole structure, especially in dynamic load status. A two-dimensional pile-soil-bridge model is built up in ANSYS based on a factual bridge. The over-deflection is considered as the decrease of beam elastic modulus or rigidity. The displacement and internal force of key parts are analysed in static and dynamic vehicle load. The study shows that over-deflection will reduce the first three natural vibration frequency, weaken the sensitivity of bridge to dynamic load. In dynamic load status, the displacement and internal force will be influenced by beam rigidity.

• Periodical: Advanced Materials Research (Volumes 446-449)
• Pages: 1067-1070
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.446-449.1067
• Online since: January 2012
• Authors: Rong Xia Wang, Xiang Shang Chen, Fan Li, Shao Wei Zhao
• Keywords: Beam Rigidity, Continuous Rigid Frame Bridge, Moving Vehicle, Two-Dimensional Pile-Soil-Bridge Model

References

[1] Liu Shanhong, Qian Yongjiu. Journal of Chongqing Jiaotong University, Vol. 24(2005),pp.19-22(In Chinese).

[2] Zhan Jianhui, Chen Hui. Journal of China and Foreign Highway, 2005,25(1): 56-58(In Chinese).

[3] Xu Zhen, Zhang Xuesong, Xu Junlan. Journal of Chongqing Jiaotong University, 2007, 26 (4): 9-13(In Chinese).

[4] Wang Fawu. The study on the control of long-term deflection of large span prestressed concrete beam bridge. Master's degree thesis of Tongji University( 2006) (In Chinese) .

[5] Zhang Shihui. The analysis on reason of the overdeflection and construction control of large span prestressed concrete continuous rigid frame bridge. Master's degree thesis of Chongqing Jiaotong University, (2007) (In Chinese).
