Research on Mechanical Model and Fatigue Crack of Tubular Joint

Abstract:

When the tubular joint is under stress, the stressed conditions on the intersection line are rather complicated. This article proposes to establish a cylindrical coordinated system for the stress on a tubular joint with axial direction, radical direction and circumferential direction as directions of coordinate axis. The system resolves the stress on points of the line of intersection along those three directions and establishes a mechanical analysis model for the stress on the tubular joint based on that. Besides, with combination of conditions of fatigue cracks of tubular joint, effective tensile stress specific to I-shape cracks are put forward and relevant mechanical formula are deduced accordingly. By taking fatigue tests of tubular joints of CaoEJiang Bridge as examples, the article also works out the position of the maximum geometrical value of stress on the line of intersection of tubular joint with applications of mechanical models and computational formula presented in the paper and compares the position with the result of test to explain the result of test.

• Periodical: Advanced Materials Research (Volumes 446-449)
• Pages: 278-282
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.446-449.278
• Online since: January 2012
• Authors: Diao Yan
• Keywords: Fatigue Test, Mechanical Model, Position of Cracking Points, Tubular Joint

References

[1] Szlendak J, Brodka J. Strengthening of T moment of RHS joints[J].Proc Instn Civ Engrs, Part 2,1985,79:717-727.

DOI: 10.1680/iicep.1985.767

[2] Fessler H, Mockford P B, Webster J J. Parametric equations for the flexibility matrices of single brace tubular joints in offshore structures[J].Proc Instn Civ.Engrs,Part 2,1986,81:675-696.

DOI: 10.1680/iicep.1986.467

[3] Fessler H, Mockford P B, Webster J J.Parametric equations for the flexibilit y matrices of multi-brace tubular joints in offshore structures[J].Proc Instn Civ.Engrs,Part 2,1986,81:659-673.

DOI: 10.1680/iicep.1986.466

[4] Cheng xiangming.Elastic Plastic Mechanic.Beijing Science Press (2007)

[5] Chen yiyi,intersection circular steel tube bending stiffness and bearing capacity of test nodes. Journal of Building structure 2001,22(6)25/30

[6] Liu peng.Radius of the Converging plane stiffness of steel node.Department of architectural engineering Shanghai Tongji University,(2001)

[7] Wang wei,Chen yiyi.Steel tube intersection node local stiffness parameters formular.Journal of Tong ji University
