Calculation of Areas of Cultural Relics Surface Defects Based on the Triangular Mesh Model

Abstract:

In order to solve the problem that need exact and scientific data in checking and restoring cultural relics, this paper presents a novel algorithm that statistics defect areas of cultural relics by calculating holes area in the in triangular mesh models.First, build the topological relationship between triangles, vertices and edges and extract boundary using boundary property of triangular mesh. Next, the holes bounding edges are linked in sequence into holes polygon. Finally, distinguish holes boundary and model exterior boundary by means of triangular mesh topological characteristics and the areas of three-dimensional holes polygon are calculated to statistics defect areas of cultural relics through the method of coordinate. Through experiments, it proved that this algorithm was correctly and reasonable.

• Periodical: Advanced Materials Research (Volumes 446-449)
• Pages: 3452-3456
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.446-449.3452
• Online since: January 2012
• Authors: Xiao Qing Zhang, Miao Le Hou, Guang Zhu, Yun Gang Hu
• Keywords: Boundary Extraction, Holes Area, Triangular Mesh

References

[1] John Branch, Flavio Prieto, Pierre Boulanger. A Hole-Filling Algorithm for Triangular Meshes Using Local Radial Basis Function[C]. In Philippe P. Pbay, editor, Proceedings of the 15th International Meshing Roundtable, pages 411-431. Springer Berlin Heidelberg, 2006.

DOI: 10.1007/978-3-540-34958-7_24

[2] Liyan Zhang, Rurong Zhou, Laishui Zhou. Research on the Algorithm of Hole Repairing in Mesh Surfaces[J].Journal of Applied Sciences 2002,20(3):221-224.(in Chinese)

[3] Xianying Zhang, Mingquan Zhou, Guohua Geng. A Method of Detecting the Edge of Triangular Mesh Surface [J].Journal of Image and Graphics, 2003, 8(10): 1223-1226. (in Chinese)

[4] Qing Yu, Jiechen Wang, Yanming Chen. A Method of Boundary Extraction for Triangle Mesh [J]. Science of Surveying and Mapping, 2009, 34：82-83. (in Chinese)

[5] Shenglan Liu, Rurong Zhou, Liyan Zhang. Feature Line Extraction from Triangular Mesh Model[J].Journal of Computer Aided Design & Computer Graphics,2003，15(4)：445-448．(in Chinese)

[6] Pinhu Wei, Wei Xiao. Calculation of Three-Dimensional Polygon [J], Mathematics bulletin, 1984(02). (in Chinese)

[7] Pernot, J. P., Moraru, G.,Veron, P. Filling Holes in Meshes Using a Mechanical Model to Simulate the Curvature Variation Minimization, Computers & Graphics, 30(6), 2006, 892-902.

DOI: 10.1016/j.cag.2006.08.020

[8] Renjian Zhai, Fang Wu, Benxin Xue. An Optimal Triangulation Algorithm for General Polygon Based on Edge Prior [J]. Science of surveying and mapping, 2008, 33 (1):122-125. (in Chinese)

[9] Qiang Liu, Deren Li. A Recursive Algorithm for Triangulation of Arbitrary Polygons Based on BSP Tree [J], Geomatics and Information Science of Wuhan University.2002, 27(5): 528-533. (in Chinese)
