Welding Residual Stress of Flange-Plate Steel Reinforced Connections

Abstract:

The welding joint method is usually applied in the reinforcing process of the steel moment frame connections. The welding parameters are chosen and discussed and the finite element analysis is employed to analyze the completely penetration joint weld between the flange plates and the column flange. The three-dimensional thermo-structure simulation is conducted. Furthermore, the influence of the residual stresses on the the loading capacity of the reinforced connection is discussed. The temperature field during the welding process and the residual stresses distribution are given. The existence of the welding residual will highly increase the likelihood of brittle fracture of the steel in the heat affect zone.

• Periodical: Advanced Materials Research (Volumes 446-449)
• Pages: 3495-3498
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.446-449.3495
• Online since: January 2012
• Authors: Wei Wang, Chang Hao Zhang, Guan Feng Wang, Juan Zhang
• Keywords: Finite Element Analysis (FEA), Residual Stress, Steel Moment Connection, Temperature Field, Welding

References

[1] Duane K. Miller, Lessons Learned from the Northridge Earthquake, Engineering Structures, vol.20，1998，PP249-260

[2] A Survey Report for Building Damages Due to The 1995 Hyogo-Ken Nanbu Earthquake, Building Research Institute Ministry of Construction,Japan,1996.3

[3] Kim T, Kim J. Collapse analysis of steel moment frames with various seismic connections[J]. Journal of Constructional Steel Research (2008), 2008.11

DOI: 10.1016/j.jcsr.2008.11.006

[4] WANG Yan , YU You-sheng , WANG Peng. Experimental Study on Mechanics Property of Flange Plate-Reinforced Connections of Steel Frames[J]. Engineering Mechanics, vol.28 (3), 2011, PP177-260

[5] FEMA-350. Recommended Seismic design Criteria for New Steel Moment-frame Buildings [M]. 2000 , Washington, D.C.

[6] Gao Zhong-min. Practical Welding Technology [M]. Beijing: Golden Shield Press,2003.
