Research on the Ultimate Bearing Capacity Analysis of TK-Joints by Finite Element Analysis

Abstract:

By considering the nonlinearity of material and geometric, the finite element analysis is performed for the circular tubular TK-Joints to demonstrate the stress distribution. plastic-zones and deformation of joints is studied on multi-planer XK steel tubular joints through various geometric parameters by using the nonlinear finite element analysis in this paper. The primary parameters and the influence of these parameters on the ultimate strength are investigated. Based on the bearing capacity formula of K- joint and some reference data, the strength formula for multi-planar XK joints is suggested in view of the effects of multi-staff intersection and multi-axis bearing force. These formulas provide the academic basis for construction design.

• Periodical: Advanced Materials Research (Volumes 446-449)
• Pages: 513-516
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.446-449.513
• Online since: January 2012
• Authors: Li Hui Cao, Yan Yu, Yu Zhang
• Keywords: Multi-Planar Joints, Nonlinear Finite Element, Plastic Deformation, Steel Tube Structure, Ultimate Strength

References

[1] Wang B, Hu N, Kurobane Y, et al. Damage criterion and assessment approach to tubular joints [J]. Engineering Structures, 2000，20(22): 567~580

DOI: 10.1016/s0141-0296(98)00134-5

[2] LiuJianping,GuoYanlin．Analysis of Inelastic, large Deflection Finite Element for the Tubular Joints [J]．Journal of Qinghai University，2001，19(1)：38~42

[3] LiuJianping,GuoYanlin,ChenGuodong．Ultimate Strength Analysis of Circular Tubular Joints by Finite Element Method [J]．Building Structures，2002，32(7)：56~59

[4] ShuXuanwu,ZhuQinke．Ultimate Bearing Capacity Analysis of Circular Tubular KK-Joints by Finite Element Method [J]．Journal of South China University of Technology，2002，30(10)：102~106

[5] ZhuShaoning,ShuXingping．Ultimate Bearing Capacity Analysis of Circular Tubular KK-Joints by Nonlinear finite element analysis Method [J]．HuNan

[6] ChenYiyi,ChenYanji,ZhanChen,et al．Experimental Research On Multi-planar Joints Of Steel Tubular Members [J]．China Civil Engineering Journal，2003，36(8)：24~30

[7] ZhanChen．Research On Full Scale Test Of Welded Circular Tubular Joints [D]．ShangHai：TongJi University，(2000)

[8] Yura J A, Howell L E, Frank K H. Ultimate load tests on tubular connections [R]. Texas: Civil Engineering Structural Research Laboratory, (1978)

[9] ChenYiyi,ShenZuyan,ZhanChen,et al．Three Lines Limit-analysis Model For Chs k-joints And Its Verification By Tests [J]．China Civil Engineering Journal，1999，32(6)：26~39

[10] LiuJianping．The Status And Trend Of Research On Steel Tubular Intersecting Joints [J]．Steel Construction，2003，18(4)：13~15

[11] ENV 1993-1-1, Eurocode 3[S]

[12] Architectural Institute of Japan．Architectural Institute of Japan. Recommendations for the design and fabrication of tubular structures in steel [M]．Architectural Institute of Japan，(1990)

[13] Wardenier J, Kurobane Y, Packer J A. Design guide for circular hollow section (CHS) joints under predominantly static loading [M]. Verlag TUV Rheinland, (1991)

[14] GBJ17－88，China Design Code of Steel Structures [S]

[15] ChenYiyi,ShenZuyan,ZhanChen,et al．Design Formulae For The Strength Of Steel Tubular Joints [J]．Steel Construction，1999，14(43)：53~56
