Dynamic Analysis of Large-Scale Power House

Abstract:

The underwater structure of power house is major structure under the dynamic loads of unit. The vibration problem is very common in operation. So the structures should have sufficient stiffness to resist dynamic loads of unit. This paper establishes three-dimensional finite element models with finite element analysis software—ANSYS. Dynamic characteristics of the power house and dynamic responses of structure under earthquake are analyzed. The results of the computation show that fluid-solid coupling may be ignored when studying dynamic characteristics of structures of the underground power house.

• Periodical: Advanced Materials Research (Volumes 446-449)
• Pages: 837-840
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.446-449.837
• Online since: January 2012
• Authors: Yu Zhao, Shu Fang Yuan, Jian Wei Zhang
• Keywords: Dynamic Analysis, Finite Element Model (FEM), Power House

References

[1] The Ministry of Water Resources of the PRC, The Design Criterion of Powerhouse of Hydropower Station (SL266-2001), Beijing: China Water Power Press. In Chinese.

[2] Ji Jianlian, Wang Haijun, Study of Power Plant Structure [M], Beijing: China Water Power Press. In Chinese.

[3] Wang Haijun, Composite Structure and Dynamic Analysis of Power Plant [D], Tianjin University, 2005. In Chinese.

[4] Ma Zhenyue, Dong Yuxin, Dynamic Response of Hydraulic Turbine Sets under Water Power Load, Journal of Hydroelectric Engineering, 1990. In Chinese.

[5] Dong Liuxin, Ma Zhenyue, The Vibration Evaluation of Water-Wheel Generator Set. Large Electric Machine and Hydraulic Turbin, 1990. In Chinese.

[6] Zhang Jianwei, Lian Jijian, Wang Haijun, Progress in the Research on Discharge Dynamics Inverse Problem of Hydraulic Structure. Journal of Hydraulic Engineering, 2009, 40 (11): 1326-1332. In Chinese.

[7] Shen Ke, Zhang Zhongqing, Analysis of Floor Vibration of Power Plant, Yangtze River, 2003. In Chinese.
