Intelligent Multi-Objective Optimization for High Strength Sheet Metal Forming Process of Body Part

Abstract:

In high strength sheet metal forming process of body part, crack, wrinkle and severe thinning are the main faults usually. The degree of the faults varies with the change of input process parameters. Optimization for sheet metal forming process of body part is often considered as a multi-objective problem. Design of experiment method and genetic algorithm are often combined together to cope with this multi-objective optimization problem. High strength steel sheet metal forming process is relatively complex and difficult. An intelligent multi-objective optimization strategy for high strength sheet metal forming process was suggested based on genetic algorithm. Latin Hypercube Sampling method was introduced to design the rational experimental samples; the objective function was defined based on crack factor, wrinkle factor and severe thinning factor; the accurate response surface model for sheet metal forming problem was built; Multi-objective genetic algorithm was adopted in optimization and Pareto solution was selected. The strategy was applied to analyze a rocher. The result has proved this strategy suitable for optimization design of sheet metal forming process .

• Periodical: Advanced Materials Research (Volumes 455-456)
• Pages: 1515-1520
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.455-456.1515
• Online since: January 2012
• Authors: Zhi Guo An, Yu Zhang
• Keywords: Genetic Algorithm (GA), Intelligent Multi-Objective Optimization, Multi-Objective Optimization (MOP), Response Surface Methodology (RSM), Sheet Metal Forming

References

[1] Y. Zhang, P. Zhu, G. L. Cheng, The Lightweight Design of Bonnet in Auto-Body Based on Finite Element Method, Journal of Shanghai Jiaotong University, vol. 40, no. 1, pp.163-166 , (2006).

[2] G. Gantar, T. Pepelnjak and K. Kuzman, Optimization of sheet metal forming processes by the use of numerical simulations, J Mater Process Tech vol. 130–131, pp.54-59, (2002).

DOI: 10.1016/s0924-0136(02)00786-0

[3] H. Naceur, A. Delamziere, J.L. Batoz, Some improvements on the optimum process design in deep drawing using the inverse approach, J Mater Process Tech vol. 146, pp.250-262, (2004).

DOI: 10.1016/j.jmatprotec.2003.11.015

[4] K. D. Majeske and P. C. Hammett, International Journal of Flexible Manufacturing Systems, International Journal of Flexible Manufacturing Systems, vol. 15, pp.5-18, (2003).

DOI: 10.1023/a:1023993806025

[5] J. Cao and B. L. Kinsey, Next generation stamping dies –controllability and flexibility, Robotics and Computer Integrated Manufacturing, vol. 17, pp.49-56, (2001).

DOI: 10.1016/s0736-5845(00)00036-3

[6] Q. E. Rong and C. W. CHeng, Latin hypercube sampling in ultimate strength reliability of ship hull grider, Journal of Ship Mechanics, vol. 6, no. 3, pp.52-57, (2002).

[7] R. H. Myers and D. C. Montgomery, Response Surface Methodology : Process and Product Optimization Using Designed Experiments, Wiley, New York, (1995).

[8] X. F. Mu, W. X. Yao, X. Q. Yu, A survey of surroga te models used in MDO, Chinese Journal of Computational Mechanics, vol. 2, no. 5, pp.608-613, (2005).

[9] H. P. Zhu and W. J. Li, Multiobjective Structural Optimization with Pareto Genetic Algorithm, Journal of Northwestern Polytechnical University, vol. 19, no. 1, pp.152-155, (2001).
