Contact Simulation and Analysis on Planetary Gear of Megawatt Wind Turbines Yawing Reducer

Abstract:

.According to the operation condition of megawatt wind turbines yawing reducer, an assembly model of megawatt wind turbines yawing reducer is established, and aiming at different load conditions, the tooth surface of three teeth planetary gear model is analysised with using finite element analysis software-ANSYS ,including three-dimensional nonlinear contact analysis and structural finite element analysis which simulates contact stress of engagement pairs during the operation process of planetary gear. The results indicated that when the torque is M₁=100N·m, the maximum stress on the engagement pairs is 177.584MPa; when the torque is and M₂=300N·m, the maximum stress on the engagement pairs is 329.607MPa, which were less than the yield limit of planetary gear materials, but it can meet the design and operation requirements of planetary gear of megawatt wind turbines yawing reducer.

• Periodical: Advanced Materials Research (Volumes 455-456)
• Pages: 187-193
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.455-456.187
• Online since: January 2012
• Authors: Jia Qiang E, Jiang Dong Dong, Guan Lin Liu
• Keywords: Contact Analysis, Engagement Pairs, Finite Element, Planetary Gear, Wind Turbines Yawing Reducer

References

[1] LIU Zhong-ming, DUAN Shou-min, WANGChang-lu, Development and Prospect of Design and Manufacture Technology of Gearboxes for Wind Tuibines, Joural of Mechanical Transmission, vol. 30(6), pp.1-6, (2006).

[2] Finite Element Contact Analysis of Meshing Gears in Gearbox of Wind Turbine Generator[D]. Dalian: Dalian University of Technology, (2007).

[3] YANG Sheng-hua Applications of Substructuring and Submodeling in Calculations of the Gear Stress and Deformation [A]. Engineering and Computational Mechanics in Science[C]. BEIJING: Beijing University Press, 2001: 701-707.

[4] LI Guanghui FEM Analysis of Engine Gear's Strength[D]. Taiyuan: Taiyuan University of Technology, (2007).

[5] Litvin L. F., Fuentes A., Perez G. I., Modified involute helical gears: computerized design, simulation of meshing and stress analysis, Comput. Methods in Appl. Mech. Engrg, vol. 194(36-38), pp, 3870-3901, (2005).

DOI: 10.1016/s0045-7825(03)00367-0

[6] Wang J., Howard I., The Torsional Stiffness of Involute Spur Gears, Meehanical Engineering Seienee, vol. 218(1), pp.131-142, (2004).

[7] Lee K., Analysis of the dynamic contact between rotating spur gears by finite element and multi-body dynamics techniques, Proceeding of the Institution of Mechanical Engineers, vol. 215(4), pp.423-435, (2001).

DOI: 10.1243/0954406011520850

[8] Wech M., Zruse A. Gohritz A., Determination of surface fatigue of gears material by roller tests, J. of Mechanical Design, vol. (100), pp.433-439. (1978).

DOI: 10.1115/1.3453947

[9] Celik M., Comparison of three teeth and whole body models in gear analysis, Mechanism and Machine Theory, vol. (34), pp.1227-1235, (1999).

DOI: 10.1016/s0094-114x(98)00058-5

[10] Chabert G., Dang T. T., Mathis R., An evaluation of stresses and deflection of spur gear teeth under strain, ASME Journal of Engineering for Industry, vol. 96(1), pp.85-93, (1974).

DOI: 10.1115/1.3438335

[11] LI Yong-xiang, BI Xiao-qin, ZHANG Jun-sun., Loaded Contact Analysis of a StraightTeeth Face Gear by ANSYS, Mechanical Science and Technology for Aerospace Engineering, vol. 28(7), pp.931-937, (2009).
