Purification and Fractionation of Natural Petroleum Sulfonates by Liquid-Liquid & Soxhlet Extraction

Abstract:

Natural petroleum sulfonates (PS) was separated, purified and divided into several fractions by a new method liquid-liquid & soxhlet extraction. The effects of heating time, volume ratio of extractants (isopropanol aqueous solution-50/50 (by volume) : n-pentane), gradient solvent types, extracting time & times on the separation efficiency are discussed, respectively. And the extracted mineral oil was anlalyzed by IR spectra, the average equivalent weight of each extracted PS fraction was measured by ESI-MS. The experimental results show that the volatiles in natural plant-manufactured PS can evaporate thoroughly in 3.5h at 130°C, and when the volume ratio of stated extractants is 3:1, after several times extraction & anti-extraction, the extracted mineral oil is PS-free, and the purified PS is successfully separated from inorganic salt, meanwhile the purified PS was divided into four fractions, whose average equivalent weight are (toluene extract) 595.03, (dichloromethane extract) 486.00, (isopropanol extract) 474.85 and (alcohol extract) 384.5g/mol, respectively. The proposed method is superior to the traditional liquid-liquid extraction for simplified steps and bifunction with PS purifying & fraction dividing, can separate efficiently industrial PS and other similar mixtures.

• Periodical: Advanced Materials Research (Volumes 455-456)
• Pages: 496-502
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.455-456.496
• Online since: January 2012
• Authors: Rui Xia Niu, Bo Lin Li, Biao Long
• Keywords: Fractionation, Gradient Soxhlet Extraction, Petroleum Sulfonates, Purification

References

[1] J. L. Cayias, R. S. Schechter and W. H. Wade, The utilization of petro-leum sulfonates for producing low interfacial tensions between hydrocarbons and water, Jour. Coll. Interface Sci., Vol. 59, no. 1, pp.31-38, March (1977).

DOI: 10.1016/0021-9797(77)90335-6

[2] A. C. Hall, Interfacial tension and phase behavior in systems of petro-leum sulfonate/brine/n-alkane, Coll. and Surf., Vol. 1, no. 2, pp.209-228, April (1980).

DOI: 10.1016/0166-6622(80)80007-2

[3] Reuben Sperling, Sulfonation products of mineral oil, Ind. Eng. Chem., vol. 40, no. 5, pp.890-897, May (1948).

DOI: 10.1021/ie50461a024

[4] J. Lu, K. -M. Su, Zh. -Z. Yan, et al, Constitution and structure analysis of petroleum sulfonates used as detergent-dispersant, Lubricating Oil, vol. 11, no. 3, pp.44-63, June (1996).

[5] F. Yu, W. -Y. Fan, G. -Z. Nan, et al, Relation between structure and property of fractions of petroleum sulfonates, Acta petrole sinica (petroleum processing section)，vol. 24, no. 2, pp.204-210, April (2008).

[6] B. Cheng, Zh. -J. Zhang, Ch. -H Liang, Analysis on Composition and Structure of Sodium Petroleum Sulfonate for EOR, Advances in fine petrochemicals, vol. 5, no. 6, pp.14-19, June (2004).

[7] X. -Sh. Wang, H. -M. Liu, X. Liu, et al, Structure Analysis of Petroleum Sulfonate used in Tertiary Oil Recovery by GC-MS. Petrochemical technology, vol. 39, no. 3, pp.336-339, (2010).

[8] Sandvik E. L, Gale W.W., Characterization of Petroleum Sulfonates, Soc. Pet. Eng., vol. 17, no. 3, pp.184-192, June (1977).

[9] F. M. Archibald, and E. L. Baldedchwieler, Analysis of Petroleum Oil-Soluble Sulfonic Acid Soaps, Ind. Eng. Chem. Anal. Ed., vol. 13, no. 9, pp.608-611, September (1941).

DOI: 10.1021/i560097a009

[10] M. K. John, Analysis of Petroleum Oil-Soluble Sodium Sulfonates by Adsorption, Ind. Eng. Chem. Anal. Ed., vol. 16, no. 1, pp.25-28, January (1944).

DOI: 10.1021/i560125a008

[11] F. Brooks, E. D. Peters, L. Lykken, Analysis of petroleum sulfonates. Extraction-adsorption method, Ind. Eng. Chem. Anal. Ed., vol. 18, no. 9, pp.544-547, September (1946).

DOI: 10.1021/i560157a007

[12] P. I. Brewer, The Determination of Oil-Soluble sulphonates by Two-phase Titration, Inst. Pet., Vol. 58, no. 559, pp.41-46, January (1972).

[13] W. W. Gale, E. I. Sandvik, Tertiary surfactant flooding petroleum sulfonate composition-efficacy studies, Soc. Pet. Eng., vol. 13, no. 4, pp.191-199, (1973).

DOI: 10.2118/3804-pa

[14] H. -Y. Jiang, F. -H. Rao, B. -Y. Jiang, Component analysis of petroleum sulfonates used in surfactant flooding, Oilfield Chem., vol. 2, no. 1, pp.75-82, Feburary (1985).

[15] G. -Q. Liang, Y. -L. Jiang and Ch. -Y. Song, Analytical method for the composition percentage, average equivalent weight and equivalent weight distribution of petroleum sulphonate, P.G. O. D. D., vol. 7, no. 3, pp.35-40, September (1988).

[16] S. Chen, D. L. Pietrzyk, Separation of sulfonate and sulfate surfactants by capillary electrophores is effect of buffer cation, Anal. Chem., vol. 65, no. 20, pp.2770-2775, October (1993).

DOI: 10.1021/ac00068a012

[17] ASTM D 3712-91 (Reapproved 2000), Standard Test Method of Analysis of Oil-Soluble Petroleum Sulfonates by Liquid Chromatography.

[18] X. -S. Wang, Y. -W. Zhu, X. Liu, et al, Analysis of Petroleum Sulfonate in Enhanced Oil Recovery by ESI-MS, Anal. Tech. Instr., vol. 16, no. 2, pp.83-88, June (2010).

[19] J. Shi, Q. -D. Li, X. -L. Dong, The component analysis and surfactactive studying on petroleum sulfonates in Karamayi refinery, Chem. Eng. Oil and Gas, vol. 29, no. 5, pp.247-249, October (2000).
