Printed-Electronic PCB Circuit Inkjet Printing Control and Detection System

Abstract:

Printed electronic technology is focus in industry as an efficient, low consumption, energy saving, environmentally friendly technology. Ink-jet printing technology is the core of fully printed electronic technology. This article design a Printed electronic Assembly line system consisted of Fixed inkjet array, which can Implement high-speed inkjet printing. It Adopt the print driver architecture In accordance with WDM models which cross kernel and user level. Embedded with electronic circuit design software systems, the electronic circuit design is directly printed to PCB. Interlaced Fixed Multi-inkjet Has parallel high-speed printing features, reduce assembly line machinery vibration, simplify electromechanical servo systems, improve the accuracy of printing. The Design Consist of sections of PCB Positioning, Image servo, Matching printing and Quality detection.

• Periodical: Advanced Materials Research (Volumes 457-458)
• Pages: 1163-1168
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.457-458.1163
• Online since: January 2012
• Authors: Yong Hong Liao
• Keywords: Circle Detection, Circuit Quality Detection, Fully Printed Electronic, Ink-Jet Printing
