Multi-Scale Hermitian Wavelet Envelope Spectrum Based Bearing Fault Detection

Abstract:

Hermitian wavelet is a low-oscillation, complex valued wavelet, which can detect the singularity characteristic of a signal precisely under strong background noise condition. A new method of bearing fault diagnosis based on multi-scale Hermitian wavelet envelope spectrum is proposed. The multi scale Hermitian wavelet envelope spectrum technique combines the advantages of Hermitian wavelet transform, envelope spectrum and three dimensions color map into one integrated technique. The bearing fault vibration signal is firstly decomposed using Hermitian continuous wavelet transform. Then the real and imaginary parts are obtained. In the end, the multi scale Hermitian wavelet envelope spectrum is obtained and the characteristics of the bearing fault can be recognized according to the multi-scale Hermitian wavelet envelope spectrum. The proposed method has been proved by vibration signals obtained from rolling bearing with inner or outer race fault. The experimental results verified the effectiveness of the proposed method.

• Periodical: Advanced Materials Research (Volume 459)
• Pages: 132-136
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.459.132
• Online since: January 2012
• Authors: Hui Li
• Keywords: Bearing, Envelope Spectrum, Fault Diagnosis, Hermitian Wavelet Transform, Signal Processing, Time Frequency Distribution

References

[1] R. Rubini and U. Meneghetti: Application of the envelope and wavelet transform analyses for the diagnosis of incipient faults in ball bearings, Mechanical Systems and Signal Processing Vol. 15, No. 2, (2001), pp.287-302.

DOI: 10.1006/mssp.2000.1330

[2] J. Lin and L. Qu: Feature extraction based on Morlet wavelet and its application for mechanical fault diagnosis, Journal of Sound and Vibration, Vol. 234, No. 1, (2000), pp.135-148.

DOI: 10.1006/jsvi.2000.2864

[3] D. Moulahbal, M. farid Golnaraghi, F. Ismail: Amplitude and phase wavelet maps for the detection of cracks in geared systems, Mechanical Systems and Signal Processing, Vol. 13, No. 3, (1999), p.423–436.

DOI: 10.1006/mssp.1998.1206

[4] Hui Li, Yuping Zhang, Haiqi Zheng: Hilbert-Huang transform and marginal spectrum for detection and diagnosis of localized defects in roller bearings. Journal of Mechanical Science and Technology, Vol. 23, No. 2, (2009), pp.291-301.

DOI: 10.1007/s12206-008-1110-5

[5] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Detection and Diagnosis Based on Teager-Huang Transform. International Journal of Wavelets, Multiresolution and Information Processing, Vol. 7, No. 5, (2009), pp.643-663.

DOI: 10.1142/s0219691309003173

[6] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Detection and Diagnosis Based on OrderTracking and Teager-Huang Transform. Journal of Mechanical Science and Technology, Vol. 24, No. 3, (2010), pp.811-822.

DOI: 10.1007/s12206-009-1211-9

[7] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Diagnosis Based on Amplitude and Phase Map of Hermitian Wavelet Transform. Journal of Mechanical Science and Technology, Vol. 25, No. 11, (2011), pp.2731-2740.

DOI: 10.1007/s12206-011-0717-0

[8] Hui Li, Yuping Zhang, Haiqi Zheng. Application of Hermitian wavelet to crack fault detection in gearbox. Mechanical Systems and Signal Processing, Vol. 25, No. 4, (2011), pp.1353-1363.

DOI: 10.1016/j.ymssp.2010.11.008
