EMD and Envelope Spectrum Based Bearing Fault Detection

Abstract:

A novel method to fault diagnosis of bearing based on empirical mode decomposition (EMD) and envelope spectrum is presented. EMD method is self-adaptive to non-stationary and non-linear signal. The methodology developed in this paper decomposes the original vibration signal in intrinsic oscillation modes, using the empirical mode decomposition. Then the envelope spectrum is applied to the selected intrinsic mode function that stands for the bearing faults. The basic principle is firstly introduced in detail. Then the EMD is applied in the research of the fault detection and diagnosis of the bearing. The experimental results show that the proposed method based on EMD and envelope spectrum analysis technique can effectively diagnose the faults of bearing.

• Periodical: Advanced Materials Research (Volume 459)
• Pages: 233-237
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.459.233
• Online since: January 2012
• Authors: Zhen Tao Li, Hui Li
• Keywords: Bearing, Empirical Mode Decomposition (EMD), Envelope Spectrum, Fault Diagnosis, Signal Processing

References

[1] J. Lin and L. Qu: Feature extraction based on Morlet wavelet and its application for mechanical fault diagnosis, Journal of Sound and Vibration, Vol. 234, No. 1, (2000), pp.135-148.

DOI: 10.1006/jsvi.2000.2864

[2] W.J. Wang, P.D. McFadden: Application of wavelets to gearbox vibration signals for fault detection, Journal of Sound and Vibration, Vol. 192, no. 5, (1996), pp.927-939.

DOI: 10.1006/jsvi.1996.0226

[3] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Detection and Diagnosis Based on Teager-Huang Transform. International Journal of Wavelets, Multiresolution and Information Processing, Vol. 7, No. 5, (2009), pp.643-663.

DOI: 10.1142/s0219691309003173

[4] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Detection and Diagnosis Based on Order Tracking and Teager-Huang Transform. Journal of Mechanical Science and Technology, Vol. 24, No. 3, (2010), pp.811-822.

DOI: 10.1007/s12206-009-1211-9

[5] Hui Li, Haiqi Zheng, Liwei Tang: Bearing Fault Diagnosis Based on Amplitude and Phase Map of Hermitian Wavelet Transform. Journal of Mechanical Science and Technology, Vol. 25, No. 11, (2011), pp.2731-2740.

DOI: 10.1007/s12206-011-0717-0

[6] N . E Huang, et al: The empirical mode decomposition and the Hilbert spectrum for nonlinear and non-stationary time series analysis. Proceeding of Royal Society London. A, Vol. 454, (1998), pp.903-995.

DOI: 10.1098/rspa.1998.0193

[7] Hui Li, Yuping Zhang, Haiqi Zheng: Hilbert-Huang transform and marginal spectrum for detection and diagnosis of localized defects in roller bearings, Journal of Mechanical Science and Technology, Vol. 23, No. 2, pp.291-301.

DOI: 10.1007/s12206-008-1110-5
