A Novel Ring Slot Resonator UWB Bandpass Filter with Two Notch-Bands

Abstract:

A novel ultra-wideband(UWB) bandpass filter with dual notch-bands and wide stop-band is proposed. The designed UWB BPF is cascading a coupled simplified composite right-left-handed (SCRLH) resonator and a ring slot resonator (RSR). The SCRLH resonator creates two different notch-bands. And the RSR unit suppresses the higher-order harmonics at the upper stop-band. The UWB BPF demonstrated good insertion/return losses and out-of-band rejections in simulation.

• Periodical: Advanced Materials Research (Volume 460)
• Pages: 62-65
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.460.62
• Online since: February 2012
• Authors: Bing Gang Xiao, Peng Ye, Zhi Yi Xie
• Keywords: Bandpass Filter (BPF), Dual Notch-Bands, RSR, SCRLH, UWB
