A New Method for Calculating the Copper Coverage of PCB

Abstract:

This paper introduces a new method to obtain the copper coverage of PCB. Board-level simulation is very important in the thermal analysis and reliability design of electronic equipment. While in the process of PCB modeling, it is difficult to obtain the coverage percentage of copper in the PCB layer. By this method, the calculation of the coverage is converted to MATLAB image processing problems, is more simple than the traditional methods and the precision is higher, with strong practical.

• Periodical: Advanced Materials Research (Volume 462)
• Pages: 129-134
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.462.129
• Online since: February 2012
• Authors: Min Jiang, Cheng Gao, Jiao Ying Huang, Gui Cui Fu, Ying Cheng
• Keywords: Copper Coverage, PCB, Reliability, Thermal Analysis, Thermal Design

References

[1] ZHANG Shixin, GAO Jin, and SHI Xiaoyu, Thermal Design and Analysis for PCB, Modern Electronics Technique, No. 18, 2007. (in Chinese).

[2] FU Gui-cui, GAO Ze-xi, FANG Zhi-qiang, and ZOU Hang, A Study on Thermal Analysis of Electronic System, Electro-Mechanical Engineering, vol. 20 , No. 1, 2004. (in Chinese).

[3] Sun Jian, Ding Yaogen and Chen Zhonglin, Research on the Thermal Analysis of PCB Circuit, Journal of Electronics & Information Technology, vol. 31, No. 4, 2009. (in Chinese).

[4] Fang Zhiqiang, Fu Guicui and Gao Zexi, Application Research on Thermal Analysis Software of Electronic Systems, Journal of Beijing University of Aeronautics and Astronautics. Vol. 29, No. 8, 2003. (in Chinese).

[5] WANG Xiaodan, MATLAB-Based System Analysis and Design: Image Processing [M], " Xi, an: Xidian University Press, (2000).

[6] Ram Viswanath, and Ihab A. Ali. Thermal Modeling of High Performance Packages in Portable Computers [J], IEEE Transactions on Compoments, Packaging, and Manufacturing Technology, 1997, 20(2): 230-240.

DOI: 10.1109/95.588579

[7] Enrico Dallago and Giuseppe Venchi. Thermal Characterization of Compact Electronic Systems: A Portable PC as a Study Case[J], IEEE Trancsactions on Power Electronics, 2002, 17(2): 187-195.

DOI: 10.1109/63.988829

[8] Anna Andonova, Nadezda Kafadarova, Valentin Videkov, and Svetozar Andreev. Investigation of Thermal Conductivity of PCB, ISSE 2009 32nd International Spring Seminar on Electronics Technology, IEEE Press , May. 2009, pp.1-5.

DOI: 10.1109/isse.2009.5207019

[9] T. F. Lemczyk, B. Mack, J. R. Culham and M. M. Yovanovich, PCB Trace Thermal Analysis and Effective Conductivity, IEEE Semiconductor Thermal Measuirement and Managerment Symposium, IEEE Press, Feb. 1991, pp.15-22.

DOI: 10.1109/stherm.1991.152906

[10] Xijin Tian and Olgierd A. Palusinski, Reliability, Thermal Analysis and Optimization Wirability Design of Multi-Layer PCB Boards, Reliability and Maintainability Symposium, IEEE Press, Jan. 2002, pp.392-398.

DOI: 10.1109/rams.2002.981673

[11] The MathWorks Inc. MATLAB Help Manual.
