Simulated Annealing Algorithm Application on Inverting Optical Constants of Thin Films

Abstract:

In thin-film thickness wideband monitoring system,in order to eliminate error accumulation effect of layers which have been deposited on layer which will be deposited, the thin-film optical constants of layers deposited must be achieved.Utilizing transmittance spectral curve which has been measured, Simulated Annealing Algorithm is applied on inversion of optical constants n,k,d.For the purpose of increasing optimization speed and algorithm efficiency,the algorithm is improved, exponent dropping temperature rate varies with acceptance probability P ;The finding range of new value is controlled adaptively according to acceptance rate when the dropping temperature is t,then the algorithm is applied on the example that is membrane ZnS is deposited on the substrate of quartz glass , n,k,d are obtained in a shorter time by optimization and their values are satisfying.

• Periodical: Advanced Materials Research (Volume 462)
• Pages: 17-25
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.462.17
• Online since: February 2012
• Authors: Xiao Yan Shang, Jun Han, Jian Feng Zhang
• Keywords: Adaptive Finding, Dropping Temperature Rate, Simulated Annealing Algorithm, Thin Film Optical Constants, Transmittance Spectrum

References

[1] Akram K. S. Aqili and Asghari Maqsood, Determination of Thickness, Refractive Index, and Thickness Irregularity for Semiconductor Thin Films from Transmission Spectra, APPLIED OPTICS, Vol. 41(2002), p.218.

DOI: 10.1364/ao.41.000218

[2] Jorge I. Cisneros, Optical Characterization of Dielectric and Semiconductor Thin Films by Use of Transmission Data, APPLIED OPTICS, Vol. 37(1998), p.5262.

DOI: 10.1364/ao.37.005262

[3] YANG Sheng-Hong, YU Zhao-Xian, LI Hui-Qiu, ZHANG Yue-Li, MO Dang, Simulated Annealing Optimization Algorithm for Inverting Ellipsometric Spectra, J. Infrared Millim. Waves, Vol. 19(2000), p.338.

[4] XU Jun-qi, LIU Meng-xia, MI Qian, A New Arithmatic to Ensure the Optical Constants of Thin Film, Applied Optics, Vol. 22(2001), p.25.

[5] Shen Weidong, Liu Xu, Ye Hui, Gu Peifu, A New Method for Determination of the Optical Constants and Thickness of Thin Film, ACTA OPTICA SINICA, Vol. 24(2004), p.885.

[6] Liu Xicheng, Wang Zhiheng, Liao Qingjun, Lai Chengjun, Determination of Optical Constants of Thin Films by Means of Transmission Spectra and Simulated Annealing Algorithm, LASER TECHNOLOGY, Vol. 27(2003), pp.94-96.

[7] ZHU Guorui, TANG Xu, WANG Ping, Application of Simulated Annealing Algorithm to BuildingLand Benchmark Price Model, Geomatics and Information Science of Wuhan University, Vol. 28(2003), p.593.

[8] GAO Shang, Research on annealing strategy in Simulated Annealing Algorithm, Aeronautical Computer Technique, Vol. 32(2002), p.20.

[9] Guo MAozu, JIANG Junfeng, Li Jingmei, Research on Cooling Sehedule Selecting Method in Simulated Annealing Algorithm, ComPuter Engineering, Vol. 26(2000), p.63.

[10] LI Jianchao SU Junhong, Research on Stimulated Annealing Algorithm of Film Optical Constant, OPTICS & OPTOELECTRONIC TECHNOLOGY, Vol. 3(2005), p.58.

[11] YAN Chun-yu, GAO Fei, ZHANG Jia-wen, FANG Xiao-ling, LIU Wei, Study on the Optical Properties of Amorphous Silicon Film by Simulated Annealing Algorithm, OPTICAL TECHNIQUE, Vol. 35(2009), p.492.

[12] WANG Xin-sheng, JIANG You-hua, LI Ren-dong, HAN Zhi-bin, Simulated Annealing Algorithm and Its Applicationon Parameter Estimates of Nonlinear Geographical Model, JOURNAL OF CENTRAL CHINA NORMAL UNIVERSITY(Nat. Sci. ), Vol. 35(2001), p.103.

[13] Yang Ruoli, Gu Jifa, An Efficient Simulated Annealing Algorithm for Global Optimization, System Engineering Theory and Practice, No. 5(1997), p.29.
